Courtesy lamps circuit, except hybrid for Toyota Camry XV50 (2011-2014)

1 6 PNK 1 RCTY WIRE 13 14 19 CANL CANH FRCY 32 29 31 IG BLK WIRE BLU WIRE COMPUTER DATA PNK LINES SYSTEM WIRE DIODE (FRONT COURTESY LIGHT) (RIGHT SIDE OF DASH) DOOR LOCKS SYSTEM DRIVER'S SIDE DOOR COURTESY LIGHT SWITCH (LOWER LEFT "B" PILLAR) ECU-ACC FUSE ECU-B 1 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FRONT PASSENGER'S SIDE DOOR COURTESY LIGHT SWITCH (LOWER RIGHT "B" PILLAR) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) LEFT FRONT COURTESY LIGHT ASSEMBLY LEFT REAR DOOR COURTESY LIGHT SWITCH (LOWER LEFT "C" PILLAR) LGCY LGYL LT BLU WIRE LT GRN WIRE LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1 MAIN BODY ECU (LEFT SIDE OF DASH) PNK WIRE RADIO SETTING CONDENSER (CENTER STOP LIGHT) RIGHT FRONT COURTESY LIGHT ASSEMBLY RIGHT REAR DOOR COURTESY LIGHT SWITCH (LOWER RIGHT "C" PILLAR) VIO WIRE W/O SLIDING ROOF W/ SLIDING ROOF WHT WIRE WHT/BLK WIRE YEL WIRE

AGND BLK WIRE BLU WIRE CERTIFICATION ECU COMPUTER DATA LINES SYSTEM CTY DOME FUSE DOME LIGHT ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) ENGINE SWITCH GND CTY GRN WIRE GRY WIRE HOT AT ALL TIMES IAB IGNITION KEY CYLINDER LIGHT LEFT STOP LIGHT ASSEMBLY (W/ SLIDING ROOF) LEFT VANITY LIGHT (W/ SLIDING ROOF) LEFT VISOR ASSEMBLY LT BLU WIRE LT GRN WIRE LUGGAGE COURTESY COMPARTMENT DOOR LOCK ASSEMBLY PNK WIRE RED WIRE RIGHT STOP LIGHT ASSEMBLY (W/ SLIDING ROOF) RIGHT VANITY LIGHT (W/ SLIDING ROOF) RIGHT VISOR ASSEMBLY ROOF CONSOLE BOX ASSEMBLY (W/ SLIDING ROOF) ROOM LIGHT ASSEMBLY 1 (W/O SLIDING ROOF) RRMP SWIL TRANSPONDER KEY AMPLIFIER (W/O SMART KEY SYSTEM) VIO WIRE W/O SLIDING ROOF W/ SLIDING ROOF WHT WIRE WHT/BLK WIRE YEL WIRE
