Horn circuit, hybrid for Toyota Camry XV50 (2011-2014)
Horn circuit, hybrid
BLK WIRE
BLU WIRE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HIGH PITCHED HORN
HO SUB ASSEMBLY
HORN FUSE
HORN RELAY
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LOW PITCHED HORN (FRONT OF ENGINE COMPT)
LT BLU WIRE
MAIN BODY ECU (LEFT SIDE OF DASH) HORN
SPIRAL CABLE
STEERING PAD SWITCH HORN SWITCH ASSEMBLY
WHT WIRE
