Backup lamps circuit, except hybrid for Toyota Camry XV50 (2011-2014)
Backup lamps circuit, except hybrid
2.5L
3.5L
BACKUP
BKUP LP FUSE
BLU WIRE
DL RB NL RL PL
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT REAR LIGHT ASSEMBLY
LT BLU WIRE
PARK/NEUTRAL POSITION SWITCH (TOP OF TRANSAXLE)
PNK WIRE
RED WIRE
REV
RIGHT REAR LIGHT ASSEMBLY
TRANSMISSION CONTROL ECU (3.5L) (LEFT FRONT OF ENGINE COMPT)
W/ MULTI-MEDIA MODULE RECEIVER W/O MULTI-MEDIA MODULE RECEIVER
WHT/BLK WIRE
