3.5l, electronic power steering circuit for Toyota Camry XV50 (2011-2014)
3.5l, electronic power steering circuit
1 2 3 4 5 6 7 8 IG
1 2 PIG PGND
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN I/F
CANH TS
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-B 1 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
EPS FUSE
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRU- MENT PANEL J/B (LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/C
LED DRIVER
LT BLU WIRE
ORG/ WIRE
PHC PHB PHA
PNK WIRE
POWER STEERING ECU (LEFT SIDE OF DASH)
POWER STEERING MOTOR ASSEMBLY
RED WIRE
TELLTALES
TORQUE SENSOR
TRQG TRQF TRQV
VIO WIRE
WHT WIRE
YEL WIRE
