Computer data lines circuit, hybrid for Toyota Camry XV50 (2011-2014)

1 2 CANH CANL 11 12 CANH CANL 2 3 CANL CANH 9 10 9 10 CANH CANL A/C AMPLIFIER (RIGHT SIDE OF DASH) BLK WIRE BLU WIRE BRN WIRE CANL TC TS PNK WIRE CANN CANP CERTIFICATION ECU (RIGHT SIDE OF DASH) CLEARANCE WARNING ECU (BEHIND RIGHT SIDE OF DASH) DCM (TELEMATICS TRANSCEIVER) (BEHIND RIGHT SIDE OF DASH) ECM (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) LT BLU WIRE OBD FUSE OCCUPANT DETECTION ECU ORG/ WIRE PNK WIRE POWER STEERING ECU (LEFT SIDE OF DASH) PRST RECEIVER SUB-ASSEMBLY, W/ DISPLAY 10 SPEAKERS, 6 SPEAKERS RED WIRE RIGHT FRONT SEAT INNER BELT ASSEMBLY SIL SPDL HEADLIGHT LEVELING ECU (BEHIND LEFT SIDE OF DASH) STEERING SENSOR (STEERING COLUMN) TAC LVL SIL CANH SG CG TACH VIO WIRE W/ HEADLIGHT BEAM LEVEL CONTROL (AUTOMATIC) W/ MULTI-MEDIA MODULE RECEIVER SUB-ASSEMBLY W/O MULT-MEDIA MODULE W/ SAFETY CONNECT W/O FRONT PASSENGER'S POWER SEAT W/ FRONT PASSENGER'S POWER SEAT W/O SAFETY CONNECT WHT WIRE WHT/BLK WIRE YEL WIRE

11 35 34 TC 13 14 CANL CANH PNK WIRE 15 16 CANL CANH AIRBAG SENSOR ASSEMBLY (LOWER CENTER OF DASH) BLK WIRE BLU WIRE COMBINATION METER ASSEMBLY GRN WIRE GRY WIRE JUNCTION TERMINAL LEFT BLIND SPOT MONITOR SENSOR (LEFT SIDE OF REAR BUMPER) LT GRN WIRE MAIN BODY ECU (LEFT SIDE OF DASH) PNK WIRE POWER MANAGEMENT CONTROL ECU (LEFT SIDE OF DASH) RED WIRE RIGHT BLIND SPOT MONITOR SENSOR (RIGHT SIDE OF VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
