Immobilizer circuit, except hybrid without smart key system for Toyota Camry XV50 (2011-2014)
Immobilizer circuit, except hybrid without smart key system
A/C CONTROL ASSEMBLY (CENTER OF DASH)
AGND
BLU WIRE
BRN WIRE
CODE
COMPUTER DATA LINES SYSTEM
ECM (LEFT SIDE OF ENGINE COMPT)
EFII
EFIO
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ECU-B 1 FUSE ENGINE COMPT)
HOT IN ON OR START
IGNITION KEY CYLINDER LIGHT IND
IMI
IMO
IND
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
RED WIRE
SECURITY INDICATOR
TRANSPONDER ILL- KEY AMPLIFIER (IN STEERING COLUMN)
TRANSPONDER KEY COIL
TRANSPONDER KEY ECU ASSEMBLY (BEHIND LEFT CENTER OF DASH)
TXCT
TXCT ILL+
UNLOCK WARNING SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
