Toyota Camry XV50 (2011-2014) pnk power distribution system code Wiring diagram
This page shows the only wiring diagram for the component.pnk power distribution system code, which is found in the car Toyota Camry XV50 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk power distribution system code (1 of 1)
+ECU
ACCD IG POWER DISTRIBUTION SYSTEM
AGND
ANT- ENNA COIL
BLK WIRE
BLU WIRE
CANH CANL SWIL LIN IND COMPUTER DATA LINES SYSTEM
CERTIFICATION ECU (RIGHT SIDE OF DASH)
DUMY EFIO EFII
DUMY STA STARTING/CHARGING SYSTEM
ECU-B 1 FUSE
ENGINE SWITCH
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
LUGGAGE DOOR OPENING SWITCH ASSEMBLY
PNK POWER DISTRIBUTION SYSTEM CODE WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM CUTB
RED WIRE
SHIFT INTERLOCK SYSTEM
SLR+ SHIFT INTERLOCK SYSTEM
STARTING/CHARGING SYSTEM
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
TXCT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power door locks circuit, except hybrid with smart key system (5 of 5) -> PNK POWER DISTRIBUTION SYSTEM CODE WIRE
