Heated seats circuit for Toyota Camry XV40 facelift (2009-2011)
Heated seats circuit
BLK WIRE
BLU WIRE
BRN WIRE
GRN WIRE
HOT IN ON OR START INSTRUMENT S-HTR FUSE PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C
LEFT SEAT HEATER (DRIVER'S SEAT)
LEFT SIDE SEAT SWITCH
PNK WIRE
RIGHT SEAT HEATER
SEAT BACK (PASSENGER'S SEAT)
SEAT BACK)
SEAT CUSHION)
SEAT HEATER SWITCH
SEAT SWITCH RIGHT SIDE
WHT/BLK WIRE
