Immobilizer circuit, hybrid for Toyota Camry XV40 facelift (2009-2011)

1 2 3 4 5 6 7 8 B+ 41 42 IMO IMI BLU WIRE CERTIFICATION ECU (BEHIND RIGHT SIDE OF DASH) EFI 1 FUSE EFII EFIO ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) GRN WIRE HOT AT ALL TIMES ID CODE BOX (BEHIND LEFT SIDE OF DASH) J/B 3 (BEHIND LEFT SIDE OF DASH) J/B 4 (BEHIND CENTER OF DASH) LIN LT GRN WIRE MAIN BODY ECU (BEHIND LEFT SIDE OF DASH) OF DASH) INSTRUMENT PANEL J/B ORG/ WIRE STEERING LOCK ECU (BEHIND CENTER OF DASH) WHT WIRE WHT/BLK WIRE YEL WIRE
