Toyota Camry XV40 facelift (2009-2011) micro computer Wiring diagrams
This page contains all the electrical diagrams for the component. micro computer, in which he is found in the car Toyota Camry XV40 facelift (2009-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram micro computer (31 of 32)
1 2 3 4 5 6 7 8 9 10 11 12 IG
BLK WIRE
BRN WIRE
CAN I/F
CANN
CANP GND CLSW RDA
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVER IC
ECU- IG 1 FUSE
GAUGE 2 FUSE
GRN WIRE
GRY WIRE
HOT IN ON OR START
INSTRUMENT PANEL J/B
J/B 3 (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
MICRO COMPUTER
ORG/ WIRE
POWER SUPPLY CIRCUIT
RDA GND
TIRE PRE- SSURE IND
TIRE PRESSURE WARNING ANTENNA, RECEIVER (RIGHT "C" PILLAR)
TIRE PRESSURE WARNING ECU (BEHIND RIGHT SIDE OF DASH)
TIRE PRESSURE WARNING RESET SWITCH (BEHIND RIGHT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
Go to component -> Tire pressure monitoring circuit, hybrid -> MICRO COMPUTER
Wiring diagram micro computer (32 of 32)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
EXCEPT HYBRID
FRONT WASHER SWITCH
FRONT WIPER SWITCH
GAUGE 2 FUSE
GRN WIRE
GRY WIRE
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/B 3 (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR
LT GRN WIRE
MICRO COMPUTER
MIST
MIST HI OFF LO
MIST HI OFF LO INT
MIST HI OFF LO INT INT
OFF INT
PNK WIRE
POWER SUPPLY CIRCUIT
RED WIRE
SOLID STATE
WASH FUSE
WASHER LEVEL WARNING SWITCH (WASHER FLUID RESERVOIR)
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER SWITCH ASSEMBLY
WIP FUSE
WIPER RELAY
Go to component -> Wiper/washer circuit -> MICRO COMPUTER
