Car Wiring Diagrams for Power windows circuit, convertible for Toyota Camry XV30 (2001-2006)

1 2 4 5 8 10 LRD 1 5 6 7 8 10 12 PPSD RRD PSU PPSU PSM 2 3 4 5 7 8 9 10 SPD SU DD EIG TDU SD 3 5 6 CLS OPEN ALT FUSE BLK WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BODY ECU (BEHIND LEFT SIDE OF DASH) BRN WIRE BV (BEHIND LEFT REAR SEAT) COMBINATION METER CONVERTIBLE ROOF CONTROL RELAY (AT LEFT FRONT OF TRUNK) DRIVER SIDE J/B (LOWER LEFT END OF DASH) ECU-B FUSE ECU-IG FUSE ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START II (AT LEFT "A" PILLAR) IJ (BEHIND FRONT OF CENTER CONSOLE) J/C 16, J/C 17 (BEHIND LEFT REAR SEAT) J/C 3 (BEHIND LEFT SIDE OF DASH) LEFT FRONT POWER WINDOW MOTOR LEFT QUARTER POWER WINDOW MOTOR LRU+ PASSENGER SIDE J/B (BEHIND RIGHT SIDE OF DASH) PDD BW IG PDU PNK WIRE POWER WINDOW MASTER SWITCH POWER WINDOW SWITCH (ALL WINDOW) PWR FUSE P/W 2 FUSE PWR RELAY PWS RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT FRONT POWER WINDOW MOTOR RIGHT FRONT POWER WINDOW SWITCH RIGHT QUARTER POWER WINDOW MOTOR RRU TSK FUSE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE WLSW
