Car Wiring Diagrams for Heated seats circuit for Toyota Camry XV30 (2001-2006)

BLU WIRE BO (UNDER DRIVER'S SEAT) BP (UNDER FRONT PASSENGER'S SEAT) DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) DRIVER'S SEAT HEATER SWITCH FRONT PASSENGER'S SEAT HEATER SWITCH ILL ILL GRN WIRE HOT IN ON OR START IG ILL+ ILL- J/C 18, 19 J/C 18, 19 (W/ POWER SEAT) J/C 20, 21 J/C 4 (BELOW FRONT OF CENTER FLOOR CONSOLE) LEFT SEAT HEATER RED/BLK WIRE RED/YEL WIRE RIGHT SEAT HEATER SEAT HTR FUSE WHT WIRE WHT/BLK WIRE
