Toyota Camry XV30 (2001-2006) low solid state int Wiring diagram
This page shows the only wiring diagram for the component.low solid state int, which is found in the car Toyota Camry XV30 (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low solid state int (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/YEL WIRE
COMBINATION METER
COMBINATION SWITCH
DRIVER SIDE J/B (BEHIND LEFT SIDE OF DASH) WIPER FUSE
ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT)
FRONT WIPER MOTOR (ON LEFT SIDE OF FIREWALL)
FUSE
HOT IN ON OR START
INT TIME
J/C 4 (BELOW FRONT OF CENTER FLOOR CONSOLE)
LOW SOLID STATE INT
OFF
ORG/ WIRE
PNK WIRE
PNK/BLU WIRE
WASHER FUSE
WASHER LEVEL IND
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WIPER SWITCH
Go to component -> Wiper/washer circuit -> LOW SOLID STATE INT
