Immobilizer circuit for Toyota Camry XV20 (1994-2002)
Immobilizer circuit
1 2 3 4 5 PWR CODE RXCK TXCT GND
1 8 1 8 BATT MREL
2.2L
25 26 11 16 KSW IMLD
28 19 18 4 5 10 CODE RXCK TXCT
3.0L
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
COMBINATION METER
EFI FUSE
EFI RELAY
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM J/B 2 (LEFT SIDE OF ENGINE COMPT)
EOM
GRN/WHT WIRE
HOT AT ALL TIMES
J/C 27, J/C 28 (BEHIND RIGHT SIDE OF DASH)
J/C 35 (BEHIND RIGHT KICK PANEL)
J/C 8 (BEHIND LEFT SIDE OF DASH)
J/C 9, J/C 10 (TOP CENTER OF DASH)
RED/BLU WIRE
RED/YEL WIRE
TRANSPONDER KEY AMPLIFIER (ON RIGHT SIDE OF STEERING COLUMN)
UNLOCK WARNING SWITCH
WHT/BLK WIRE
