Toyota Camry XV10 (1991-1997) Instrument illumination circuit

1996: BUILT-IN TYPE AMPLIFIER 1995: W/O CD PLAYER 1996: SEPARATE TYPE AMPLIFIER 1995: W/ CD PLAYER A/T ONLY A/T ONLY A/T INDICATOR LIGHT (SHIFT LEVER) A/T ONLY COMBINATION METER A/T INDICATOR LIGHT ASHTRAY ILLUMINATION BLK WIRE BLOWER SWITCH ILLUM- INATION A/C, HEATER CONTROL SWITCH ILLUM- INATION CIGARETTE LIGHTER ILLUMINATION CLOCK COMB- INATION METER METER ILL COMBINATION SWITCH LIGHT CONTROL SWITCH ECT PATTERN SELECT SWITCH ILLUMINATION A/T ONLY GLOVE BOX LIGHT GLOVE BOX LIGHT SWITCH GRN WIRE HAZARD SWITCH ILLUMINATION HOT AT ALL TIMES INTEGRATION RELAY (ON REAR OF J/B 1) J/B 1 (BEHIND DASH, LEFT OF STEERING COLUMN) J/B 3 (BEHIND METER ASSEMBLY) J/C 2 (RIGHT SIDE OF DASH) OFF HEAD TAIL RADIO AND PLAYER ILLUMINATION REAR WINDOW DEFOGGER SWITCH ILLUMINATION RED WIRE RHEOSTAT (LEFT KICK PANEL) TAIL FUSE TAIL LIGHT RELAY WHT WIRE WHT/BLK WIRE WHT/GRN (OR BLK) WIRE WHT/GRN WIRE
