Ground distribution circuit for Toyota Camry XV10 (1991-1997)

1996 ONLY ABS ACTUATOR (JAPANESE PRODUCTION) ABS ACTUATOR, ECU (UNITED STATES PRODUCTION) ABS ECU (JAPANESE PRODUCTION) ABS RELAY BRN WIRE CANADA ONLY COMBINATION METER COOLING FAN RELAY 3 COOLING FAN RELAY 2 DATA LINK CONNECTOR 1 DATA LINK CONNECTOR 2 DRL RELAY NO. 4 DRL RELAY NO. 3 EFI RELAY ENGINE CONTROL MODULE ENGINE COOLANT TEMPERATURE SWITCH ENGINE MAIN RELAY FRONT WIPER MOTOR FUEL SENDER J/B 2 (BEHIND LEFT HEADLIGHT, ON FENDER APRON) J/B 3 (BEHIND COMBINATION METER) LEFT FRONT SIDE MARKER, PARKING LIGHT LEFT FRONT TURN SIGNAL LIGHT LEFT LOW BEAM HEADLIGHT NCA WIRE NOISE FILTER (IGNITION SYSTEM) OXYGEN SENSOR (BANK 1 SENSOR 1) OXYGEN SENSOR (BANK 1 SENSOR 2) RADIATOR FAN MOTOR RIGHT FRONT SIDE MARKER, PARKING LIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT LOW BEAM HEADLIGHT WHT/BLK (OR BRN) WIRE WHT/BLK WIRE

1995 ONLY 49 STATES M/T ONLY ABS ACTUATOR (JAPANESE PRODUCTION) ABS ACTUATOR, ECU (UNITED STATES PRODUCTION) ABS ECU (JAPANESE PRODUCTION) ABS RELAY BRN WIRE CALIFORNIA M/T AND 50 STATES A/T CANADA ONLY COMBINATION METER COOLING FAN RELAY 3 COOLING FAN RELAY 2 DATA LINK CONNECTOR 1 DATA LINK CONNECTOR 2 DRL RELAY NO. 4 DRL RELAY NO. 3 EFI RELAY ENGINE CONTROL MODULE ENGINE COOLANT TEMPERATURE SWITCH ENGINE MAIN RELAY FRONT WIPER MOTOR FUEL SENDER J/B 2 (BEHIND LEFT HEADLIGHT, ON FENDER APRON) J/B 3 (BEHIND COMBINATION METER) LEFT FRONT SIDE MARKER, PARKING LIGHT LEFT FRONT TURN SIGNAL LIGHT LEFT LOW BEAM HEADLIGHT NCA WIRE NOISE FILTER (IGNITION SYSTEM) OXYGEN SENSOR RADIATOR FAN MOTOR RIGHT FRONT SIDE MARKER, PARKING LIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT LOW BEAM HEADLIGHT WHT/BLK WIRE

A/C AMPLIFIER AIR VENT MODE CONTROL SERVO MOTOR BLK/ WHT WIRE BLOWER RESISTOR BLOWER SWITCH BRAKE FLUID LEVEL WARNING SWITCH BRN WIRE CENTER AIRBAG SENSOR ASSEMBLY CIGARETTE LIGHTER CLOCK DATA LINK CONNECTOR 3 DEFOGGER RELAY DIMMER SWITCH FROM STARTER RELAY (J/B 2) HEATER CONTROL SWITCH (PUSH TYPE) HEATER RELAY HIGH BEAM INDICATOR (CANADA ONLY) INTEGRATION RELAY J/B 1 (BEHIND LEFT SIDE OF I/P) JUNCTION CONNECTOR 1 (BEHIND COMBINATION METER) KEY INTERLOCK SOLENOID LEFT VANITY LIGHT LIGHT CONTROL SWITCH MODE CONTROL SWITCH (LEVER TYPE) MOON ROOF CONTROL SWITCH AND PERSONAL LIGHT MOON ROOF CONTROL RELAY MOON ROOF LIMIT SWITCH MOON ROOF MOTOR NOISE FILTER POWER MAIN RELAY RADIO AND PLAYER REAR WINDOW DEFOGGER SWITCH RIGHT VANITY LIGHT STEREO COMPONENT AMPLIFIER TURN SIGNAL FLASHER UNLOCK WARNING SWITCH (IGNITION SWITCH) WHT/BLK WIRE WIPER AND WASHER SWITCH YEL WIRE

* COUPE ONLY ** SEDAN/WAGON 1996 ONLY A/T INDICATOR LIGHT ALL VEHICLES AUTO ANTENNA MOTOR AND RELAY PASSENGER POWER SEAT SWITCH BACK DOOR LOCK CONTROL SWITCH (WAGON) BLK WIRE BLK/ WHT WIRE BRN WIRE COMBINATION METER DATA LINK CONNECTOR 1 DATA LINK CONNECTOR 2 DATA LINK CONNECTOR 3 DOOR LOCK CONTROL RELAY ENGINE CONTROL MODULE FROM RIGHT FRONT DOOR LOCK CONTROL SWITCH FUEL SENDER GLOVE BOX LIGHT SWITCH HIGH MOUNTED STOP LIGHT RIGHT REAR COMBINATION LIGHT REAR WIPER MOTOR IGNITER J/B 3 (BEHIND COMBINATION METER) JUNCTION CONNECTOR 2 (BEHIND RIGHT SIDE OF I/P) JUNCTION CONNECTOR 7 (BEHIND RIGHT SIDE OF I/P) LEFT REAR COMBINATION LIGHT LICENSE PLATE LIGHT LUGGAGE COMPARTMENT LIGHT SWITCH NCA WIRE NOISE FILTER (IGNITION SYSTEM) OVER DRIVE MAIN SWITCH OXYGEN SENSOR (BANK 1 SENSOR 1) OXYGEN SENSOR (BANK 1 SENSOR 2) OXYGEN SENSOR (BANK 2 SENSOR 1) REAR WINDOW DEFOGGER (COUPE/ SEDAN) REAR WINDOW DEFOGGER (WAGON ONLY) REMOTE CONTROL MIRROR SWITCH RHEOSTAT RIGHT BELT BUCKLE SWITCH RIGHT DOOR KEY LOCK/ UNLOCK SWITCH SHIFT LOCK ECU WAGON ONLY WHT/BLK WIRE

* COUPE ONLY ** SEDAN/WAGON 1995 ONLY A/T INDICATOR LIGHT ALL VEHICLES AUTO ANTENNA MOTOR AND RELAY PASSENGER POWER SEAT SWITCH BACK DOOR LOCK CONTROL SWITCH (WAGON) BLK WIRE BLK/ WHT WIRE BRN WIRE COMBINATION METER DATA LINK CONNECTOR 1 DATA LINK CONNECTOR 2 DATA LINK CONNECTOR 3 DOOR LOCK CONTROL RELAY ENGINE CONTROL MODULE FROM RIGHT FRONT DOOR LOCK CONTROL SWITCH FUEL SENDER GLOVE BOX LIGHT SWITCH HIGH MOUNTED STOP LIGHT RIGHT REAR COMBINATION LIGHT REAR WIPER MOTOR IGNITER J/B 3 (BEHIND COMBINATION METER) JUNCTION CONNECTOR 2 (BEHIND RIGHT SIDE OF I/P) JUNCTION CONNECTOR 7 (BEHIND RIGHT SIDE OF DASH) LEFT REAR COMBINATION LIGHT LICENSE PLATE LIGHT LUGGAGE COMPARTMENT LIGHT SWITCH NCA WIRE NOISE FILTER (IGNITION SYSTEM) OVER DRIVE MAIN SWITCH OXYGEN SENSOR (BANK 1 SENSOR 1) OXYGEN SENSOR (BANK 2 SENSOR 1) REAR WINDOW DEFOGGER (COUPE/ SEDAN) RIGHT BELT BUCKLE SWITCH REAR WINDOW DEFOGGER (WAGON ONLY) REMOTE CONTROL MIRROR SWITCH RHEOSTAT RIGHT DOOR KEY LOCK/ UNLOCK SWITCH SHIFT LOCK ECU WAGON ONLY WHT/BLK WIRE

* SEDAN/WAGON ** COUPE ONLY AUTO ANTENNA MOTOR AND RELAY BLK WIRE CIRCUIT OPENING RELAY COMBI- NATION METER CRUISE CONTROL CLUTCH SWITCH CRUISE CONTROL ECU CRUISE CONTROL SWITCH DAYTIME RUNNING LIGHT RELAY (MAIN) DOOR KEY CYLINDER LIGHT, SWITCH FUEL PUMP HIGH MOUNTED STOP LIGHT HIGH MOUNTED STOP LIGHT (W/O REAR SPOILER) J/B 3 (BEHIND COMBINATION METER) JUNCTION CONNECTOR 5 (BELOW LEFT 'D' PILLAR) LEFT BUCKLE SWITCH (W/ POWER SEAT) LEFT BUCKLE SWITCH (W/O POWER SEAT) LEFT DOOR KEY LOCK/ UNLOCK SWITCH LEFT FRONT DOOR LOCK MOTOR AND DOOR UNLOCK DETECTION SWITCH LEFT FRONT POWER WINDOW MASTER CONTROL SWITCH LEFT REAR COMBINATION LIGHT LICENSE PLATE LIGHT LIGHT FAILURE SENSOR POWER SEAT CONTROL SWITCH REAR WIPER RELAY RIGHT FRONT DOOR LOCK CONTROL SWITCH RIGHT FRONT DOOR LOCK MOTOR AND DOOR UNLOCK DETECTION SWITCH RIGHT REAR COMBINATION LIGHT STARTER RELAY TO J/B 1 TO JUNCTION CONNECTOR 2 WAGON ONLY WHT WIRE WHT/BLK WHT/BLK WIRE WHT/BLK WIRE
