Back-up lamps circuit for Toyota Camry V40 (1994-1998)
Back-up lamps circuit
A/T
BACK-UP LIGHT SWITCH (TOP OF TRANSAXLE)
BACKUP
BLK WIRE
GAUGE FUSE
HOT IN ON AND START
J/B 1 (BEHIND DASH, LEFT OF STEERING COLUMN)
LEFT REAR COMBINATION LIGHT
M/T
PARK/NEUTRAL POSITION SWITCH (TOP OF TRANSAXLE)
RED/BLK WIRE
RED/BLU WIRE
RIGHT REAR COMBINATION LIGHT
SEDAN, COUPE
VEHICLE SPEED SENSOR
WAGON
WHT WIRE
WHT/BLK WIRE
