Toyota Camry V40 (1994-1998) moon roof control switch and personal light moon roof control relay Wiring diagram
This page shows the only wiring diagram for the component.moon roof control switch and personal light moon roof control relay, which is found in the car Toyota Camry V40 (1994-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram moon roof control switch and personal light moon roof control relay (1 of 1)
A/C AMPLIFIER
AIR VENT MODE CONTROL SERVO MOTOR
BLK/ WHT WIRE
BLOWER RESISTOR
BLOWER SWITCH
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
CENTER AIRBAG SENSOR ASSEMBLY
CIGARETTE LIGHTER
CLOCK
DATA LINK CONNECTOR 3
DEFOGGER RELAY
DIMMER SWITCH
FROM STARTER RELAY (J/B 2)
HEATER CONTROL SWITCH (PUSH TYPE)
HEATER RELAY
HIGH BEAM INDICATOR (CANADA ONLY)
INTEGRATION RELAY
J/B 1 (BEHIND LEFT SIDE OF I/P)
JUNCTION CONNECTOR 1 (BEHIND COMBINATION METER)
KEY INTERLOCK SOLENOID
LEFT VANITY LIGHT
LIGHT CONTROL SWITCH
MODE CONTROL SWITCH (LEVER TYPE)
MOON ROOF CONTROL SWITCH AND PERSONAL LIGHT MOON ROOF CONTROL RELAY
MOON ROOF LIMIT SWITCH MOON ROOF MOTOR
NOISE FILTER
POWER MAIN RELAY
RADIO AND PLAYER
REAR WINDOW DEFOGGER SWITCH
RIGHT VANITY LIGHT
STEREO COMPONENT AMPLIFIER
TURN SIGNAL FLASHER
UNLOCK WARNING SWITCH (IGNITION SWITCH)
WHT/BLK WIRE
WIPER AND WASHER SWITCH
YEL WIRE
Go to component -> Ground distribution circuit (3 of 6) -> MOON ROOF CONTROL SWITCH AND PERSONAL LIGHT MOON ROOF CONTROL RELAY
