Toyota Camry V40 (1994-1998) comb- ination switch light ctrl switch Wiring diagrams
This page contains all the electrical diagrams for the component. comb- ination switch light ctrl switch, in which he is found in the car Toyota Camry V40 (1994-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram comb- ination switch light ctrl switch (1 of 2)
1 2 (1996) (1995) (BODY HARN, BEHIND LEFT REAR COMBINATION LIGHT)
9 LT
ALT FUSE
BLK WIRE
BLU WIRE
COMB- INATION METER
COMB- INATION METER TURN SIGNAL IND
COMB- INATION SWITCH LIGHT CTRL SWITCH
COMB- INATION SWITCH TURN SIGNAL SWITCH
FUSE BOX (ON LEFT SIDE OF ENGINE COMPT)
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
HAZ FUSE
HAZARD SWITCH
HIGH MOUNTED STOP LIGHT (W/ REAR SPOILER ONLY)
HIGH MOUNTED STOP LIGHT (W/O REAR SPOILER ONLY)
HOT AT ALL TIMES
HOT IN ON OR START
IDLE-UP DIODE (1996 ONLY)
INTEG- RATION RELAY (ON REAR OF J/B 1)
J/B 1 (BEHIND DASH, LEFT OF STEERING COLUMN)
J/B 2 (ON LEFT SIDE OF ENGINE COMPT)
J/B 3 (BEHIND METER ASSEMBLY)
J/C 1 (BELOW LEFT SIDE OF DASH)
LEFT FRONT SIDE MARKER
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR COMBINATION LIGHT TURN TAIL STOP
LICENSE PLATE LIGHT
LIGHT FAILURE SENSOR (ON LEFT SIDE OF TRUNK)
OFF
OFF HEAD
OFF ON
PARK- ING LIGHT
REAR LIGHT WARN- ING IND
RED WIRE
RIGHT FRONT SIDE MARKER
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT REAR COMBINATION LIGHT TURN
SDN
SIDE MARKER
SIDE MARKER TAIL/ STOP
SOLID STATE
STOP FUSE
STOP- LIGHT SWITCH (ABOVE BRAKE PEDAL)
TAIL
TAIL FUSE
TAIL LIGHT RELAY
TURN FUSE
TURN SIGNAL FLASHER (ON R/B 1)
W/ REAR SPOILER
W/O REAR SPOILER
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, sedan & coupe -> COMB- INATION SWITCH LIGHT CTRL SWITCH
