Ground distribution circuit, hybrid for Toyota Camry US Market XV70 (2017-2020)

BATTERY BLK WIRE BRN WIRE CAM TIMING CONTROL W/ EDU MOTOR ASSEMBLY DK GRN WIRE ENGINE WATER PUMP ASSEMBLY FAN W/ MOTOR ASSEMBLY FUEL LID W/ MOTOR LOCK ASSEMBLY FUEL PUMP CONTROL ECU INVERTER W/ CONVERTER ASSEMBLY LA (CENTER OF DASH) LEFT BLIND SPOT MONITOR SENSOR LEFT REAR COMBINATION LIGHT ASSEMBLY LEFT REAR LIGHT ASSEMBLY LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY LUGGAGE ELECTRICAL KEY SWITCH POWER STEERING ECU (RACK, PINION POWER STEERING GEAR ASSEMBLY) QUICK HEATER ASSEMBLY RADIO, DISPLAY RECEIVER ASSEMBLY REAR WINDOW DEFOGGER (BACK WINDOW GLASS) RIGHT BLIND SPOT MONITOR SENSOR RIGHT LICENSE PLATE LIGHT ASSEMBLY RIGHT REAR COMBINATION LIGHT ASSEMBLY RIGHT REAR LIGHT ASSEMBLY STEREO COMPONENT AMPLIFIER ASSEMBLY TELEPHONE TRANSCEIVER ASSEMBLY W/ LED W/O LED W/ SAFETY CONNECT W/ SEPARATE AMPLIFIER WHT WIRE WHT/BLK WIRE

A/C CONTROL ASSEMBLY AIR FUEL RATIO SENSOR 1 (BANK 1 SENSOR 1) SHIELD AIR FUEL RATIO SENSOR 2 (BANK 1 SENSOR 2) SHIELD AUTO HIGH BEAM SWITCH BLK WIRE BLOWER W/ FAN MOTOR SUB ASSEMBLY BRAKE ACTUATOR ASSEMBLY BRAKE BOOSTER PUMP ASSEMBLY BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY BRN WIRE COMBINATION METER ASSEMBLY COMPRESSOR W/ PULLEY ASSEMBLY DATA LINK CONNECTOR 3 ELECTRIC PARKING BRAKE SWITCH ASSEMBLY FUEL LID OPENER SWITCH HAZARD WARNING SIGNAL SWITCH ASSEMBLY IGCT RELAY KNOCK CONTROL SENSOR (BANK 1) SHIELD LUGGAGE COMPARTMENT DOOR OPENING SWITCH ASSEMBLY METER MIRROR SUB-ASSEMBLY NCA WIRE POWER OUTLET SOCKET PPL R/B 6 RADIO, DISPLAY RECEIVER ASSEMBLY REFRESHING SEAT SWITCH RIGHT HEADLIGHT ASSEMBLY RIGHT HEADLIGHT LIGHT CONTROL ECU ASSEMBLY (RIGHT HEADLIGHT ASSEMBLY) S/HTR F/R RELAY SHIELD SHIFT LOCK CONTROL UNIT ASSEMBLY SHIFT POSITION INDICATOR STEERING LOCK ACTUATOR ASSEMBLY SWING GRILLE ACTUATOR ASSEMBLY TELLTALE LIGHT ASSEMBLY TRANSMISSION CONTROL SWITCH (SHIFT LOCK CONTROL UNIT ASSEMBLY) USB CHARGER SOCKET VSC OFF SWITCH W/ ADAPTIVE FRONT LIGHTING SYSTEM W/ POWER OUTLET WHT WIRE WHT/BLK WIRE

BLK WIRE BRAKE ACTUATOR ASSEMBLY BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY BRAKE FLUID LEVEL WARNING SWITCH (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY) DEF RELAY EFI MAIN 2 RELAY EFI- MAIN 3 RELAY ENGINE HOOD COURTESY SWITCH (HOOD LOCK ASSEMBLY) INVERTER W/ CONVERTER ASSEMBLY INVERTER WATER PUMP W/ MOTOR ASSEMBLY LEFT FRONT SPEED SENSOR SHIELD LEFT HEADLIGHT ASSEMBLY LEFT HEADLIGHT LIGHT CONTROL ECU ASSEMBLY (LEFT HEADLIGHT ASSEMBLY) LEFT REAR AXLE HUB, BEARING ASSEMBLY SHIELD LEVEL WARNING SWITCH ASSEMBLY (WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY) MILLIMETER WAVE RADAR SENSOR ASSEMBLY PPL RIGHT FRONT SPEED SENSOR SHIELD RIGHT REAR AXLE HUB, BEARING ASSEMBLY SHIELD SHIELD SHIELD SHIELD STOP LIGHT SWITCH ASSEMBLY VVT RELAY W/ ADAPTIVE FRONT LIGHTING SYSTEM WASHER RELAY WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER MOTOR ASSEMBLY WIPER RELAY WIRELESS DOOR LOCK BUZZER

A/C AMPLIFIER ASSEMBLY ACC RELAY AIR BAG SENSOR ASSEMBLY ALL DOOR LOCK RELAY BKUP LP RELAY BLK WIRE CERTIFICATION ECU D DOOR UNLOCK RELAY DOOR BACK RELAY FORWARD RECOGNITION CAMERA GLOVE BOX LIGHT ASSEMBLY HYBRID VEHICLE CONTROL ECU ASSEMBLY INSTRUMENT PANEL J/B ASSEMBLY KA (RIGHT END OF DASH) KE (LEFT END OF DASH) L/D DOOR UNLOCK RELAY MAIN BODY ECU MOBILE WIRELESS CHARGER CRADLE ASSEMBLY NAVIGATION ECU NETWORK GATEWAY ECU P/OUTLET 2 RELAY PATTERN SELECT SWITCH ASSEMBLY PPL RAIN SENSOR (AIR CONDITIONING THERMISTOR ASSEMBLY) SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY) SPIRAL CABLE SUB-ASSEMBLY STEERING PAD SWITCH ASSEMBLY STEERING SENSOR TRANSMISSION SHIFT SWITCH ASSEMBLY VEHICLE APPROACHING SPEAKER CONTROLLER WHT WIRE

BATTERY COOLING BLOWER ASSEMBLY BLK WIRE BRN WIRE CLEARANCE WARNING ECU ASSEMBLY DOOR CONTROL SWITCH ASSEMBLY HV BATTERY JUNCTION BLOCK ASSEMBLY INNER REAR VIEW MIRROR ASSEMBLY INTER LOCK SWITCH (SERVICE PLUG GRIP) LEFT VISOR ASSEMBLY OCCUPANT DETECTION ECU PPL RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT FRONT POWER SEAT SWITCH RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT FRONT SEAT CUSHION HEATER SUB-ASSEMBLY RIGHT OUTER REAR VIEW MIRROR ASSEMBLY RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT VISOR ASSEMBLY ROOF CONSOLE BOX ASSEMBLY ROOM LIGHT ASSEMBLY SPOT LIGHT ASSEMBLY TELEVISION CAMERA CONTROLLER TO KE GROUND (DIAGRAM 4 OF 6) W/ POWER SEAT W/ REAR PERSONAL LIGHT W/ SLIDING ROOF W/O PANORAMIC VIEW MONITOR SYSTEM W/ PANORAMIC VIEW MONITOR SYSTEM W/O REAR PERSONAL LIGHT W/O SLIDING ROOF W/ SLIDING ROOF WHT WIRE WHT/BLK WIRE

BATTERY VOLTAGE SENSOR BLK WIRE BRN WIRE CANISTER PUMP MODULE HV SUPPLY BATTERY ASSEMBLY IGNITION COIL ASSEMBLY 1 IGNITION COIL ASSEMBLY 2 IGNITION COIL ASSEMBLY 3 IGNITION COIL ASSEMBLY 4 LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT FRONT POWER SEAT SWITCH LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT FRONT SEAT CUSHION HEATER SUB-ASSEMBLY LEFT OUTER REAR VIEW MIRROR ASSEMBLY LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LEFT REAR SEAT INNER W/ CENTER BELT ASSEMBLY MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY OUTER MIRROR SWITCH ASSEMBLY RIGHT REAR SEAT INNER W/ CENTER BELT ASSEMBLY STOP CENTER LIGHT SET W/O PANORAMIC VIEW MONITOR W/ PANORAMIC VIEW MONITOR WHT WIRE WHT/BLK WIRE
