Toyota Camry US Market XV70 (2017-2020) left rear occupant classification sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear occupant classification sensor, which is found in the car Toyota Camry US Market XV70 (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear occupant classification sensor (1 of 1)
BGND
BLK WIRE
BLU WIRE
BSW
BUCKLE SWITCH
BUCKLE SWITCH RIGHT FRONT SEAT INNER BELT ASSEMBLY
CANN
CANP
COMPUTER DATA LINES SYSTEM
EXCEPT HYBRID
GRN WIRE
GRY WIRE
LEFT FRONT OCCUPANT CLASSIFICATION SENSOR
LEFT REAR OCCUPANT CLASSIFICATION SENSOR
LT BLU WIRE
OCCUPANT DETECTION ECU
PNK WIRE
RED WIRE
RIGHT FRONT SEAT INNER BELT ASSEMBLY
SGD
SIG
SVC
TMC MADE
TMMK MADE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (4 of 4) -> LEFT REAR OCCUPANT CLASSIFICATION SENSOR
