Automatic a/c circuit, except hybrid for Toyota Camry US Market XV50 facelift (2014-2017)

3.5L A/C AMPLIFIER ASSEMBLY A/C EVAPORATOR TEMPERATURE SENSOR A/C PRESSURE SENSOR (A/C TUBE, ACCESSORY ASSEMBLY) A/C UNIT (A/C HARNESS ASSEMBLY) A/C-B FUSE AMBIENT TEMPERATURE SENSOR (THERMISTOR ASSEMBLY) B+ BUS BLK WIRE BLW BUS - BUS G COMPUTER DATA LINES SYSTEM CONNECTOR HOUSING COLOR (BLACK) CONNECTOR HOUSING COLOR (BLUE) CONNECTOR HOUSING COLOR (GREEN) CONNECTOR HOUSING COLOR (RED) WIRE DAMPER SERVO MOTOR (AIR INLET) DAMPER SERVO MOTOR (AIR VENT MODE) DAMPER SERVO MOTOR (LEFT FRONT SIDE AIR MIX) DAMPER SERVO MOTOR (RIGHT FRONT SIDE AIR MIX) DEFOGGER SYSTEM FLOQ GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B ASSEMBLY LOCK LT BLU WIRE LT GRN WIRE MGC PNK TAM WIRE PNK TR WIRE PNK WIRE PRE RDFG RED WIRE SG-1 SG-2 SGA SOL + TEA TSD TSP VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

2.5L 3.5L AUTOMATIC LIGHT CONTROL SENSOR BLK WIRE BLOWER MOTOR W/ FAN SUB-ASSEMBLY BLU WIRE COMPRESSOR ASSEMBLY W/ PULLEY (LOWER LEFT FRONT OF ENGINE) COOLER THERMISTOR (ROOM TEMPERATURE SENSOR) ENGINE ROOM R/B ASSEMBLY GRN WIRE HOT AT ALL TIMES HTR FUSE LT BLU WIRE LT GRN WIRE PNK WIRE RED WIRE SGFL QUFL SOL- SOL+ SOLAR SENSOR SSR- SSR+ MG+ TSL TSR VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

2.5L 3.5L 3.5L, 2.5L A/C CONTROL ASSEMBLY ALT ALT FUSE ANTI-THEFT SYSTEM BLK WIRE BLU WIRE C/FAN COMPUTER DATA LINES SYSTEM COOLING FAN ECU (3.5L) (ON COOLING FAN MOTOR) COOLING FAN MOTOR COOLING FAN MOTOR 2 E.F.I. ENGINE COOLANT TEMPERATURE SENSOR ENGINE ROOM J/B ASSEMBLY ENGINE ROOM R/B ASSEMBLY FAN FUSE FAN RELAY (2.5L) GRN WIRE HAZARD SWITCH HEATER SWITCH, SECURITY INDICATOR, HOT AT ALL TIMES HOT IN ON OR START IGN INSTRUMENT PANEL J/B ASSEMBLY INTEGRATION RELAY (ENGINE ROOM JUNCTION BLOCK ASSEMBLY) LT BLU WIRE MCLS MGCT P-AB PAON PASSENGER AIR BAG ON/OFF INDICATOR PNK WIRE REAR WINDOW DEFOGGER SWITCH, MIRROR RED WIRE RFAN RFC SUPPLEMENTAL RESTRAINTS SYSTEM VIO WIRE WHT WIRE WHT/BLK WIRE
