Power distribution circuit for Toyota C-HR I facelift (2019-2023)

ABS MTR 1 FUSE ABS- MAIN FUSE ALT FUSE BATT- MAIN FUSE BATTERY BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY C/OPN RELAY CERTIFICATION ECU CLOCK ASSEMBLY COMBINATION METER ASSEMBLY CONTINUOUSLY VARIABLE VALVE LIFT CONTROLLER ASSEMBLY D/C CUT FUSE DCM/ MAYDAY FUSE DOUBLE LOCK DOOR CONTROL RELAY ASSEMBLY DRL FUSE DRL RELAY (TMMT MADE) ECU- DCC 1 FUSE ECU-B 3 FUSE ECU-DCC 2 FUSE EFI- MAIN 1 FUSE EFI- MAIN 1 RELAY EFI-MAIN RELAY ENGINE ROOM J/B 1 ENGINE ROOM J/B 1 ENGINE ROOM J/B 1 (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B 1 EPS FUSE ETCS FUSE FROM ENGINE ROOM R/B 1 (DIAGRAM 1 OF 6) FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 3 OF 6) FUSIBLE LINK BLOCK ASSEMBLY GENERATOR ASSEMBLY GRN WIRE GRY WIRE H-LP HI FUSE H-LP HI RELAY H-LP LH FUSE H-LP LH RELAY H-LP RH FUSE H-LP RH RELAY HORN FUSE HORN RELAY IGN INJ FUSE INSTRUMENT PANEL J/B ASSEMBLY J/B-AM FUSE J/B-B FUSE LT BLU WIRE MAIN BODY ECU NOT USED ORG/ WIRE PNK WIRE POWER STEERING ECU ASSEMBLY PPL/LT BLU WIRE R/B 2 ASSEMBLY R/B 4 ASSEMBLY (CENTER OF DASH) RADIO FUSE RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE S-HORN FUSE S-HORN RELAY ST FUSE ST RELAY STARTER ASSEMBLY STEERING SENSOR TELEMATICS TRANSCEIVER TO ENGINE ROOM J/B 1 (DIAGRAM 1 OF 6) TO ENGINE ROOM J/B 1 (DIAGRAM 2 OF 6) TO INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 3 OF 6) VIO WIRE VLVMATIC FUSE W/ THEFT- DETERRENT SYSTEM W/O HEADLIGHT BEAM LEVEL CONTROL W/O LED W/ LED WHT WIRE

A/C UNIT ASSEMBLY ACCD ALL DR LOCK RELAY BLK WIRE BLK/BLU WIRE BLOWER MOTOR W/ FAN SUB-ASSEMBLY BLU WIRE CERTIFICATION ECU D DR UNLOCK RELAY D/L FUSE DEF FUSE DEF RELAY DEICER FUSE DEICER RELAY DOOR DBL/L FUSE DOUBLE LOCK DOOR CONTROL RELAY ASSEMBLY ENGINE ROOM J/B 1 ENGINE SWITCH FAN 1 FUSE FAN RELAY 1 FOG FR FUSE FR FOG RELAY FROM FUSIBLE LINK BLOCK ASSEMBLY (DIAGRAM 1 OF 6) FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 3 OF 6) FUEL OPN FUSE FUEL OPN RELAY GRN WIRE GRY WIRE HTR FUSE INSTRUMENT PANEL J/B ASSEMBLY L/D-DR UNLOCK RELAY LEFT SEAT HEATER CONTROL SUB-ASSEMBLY LOCK LOCK OFF LT BLU WIRE LT GRN WIRE ON OFF ORG/ WIRE PARK/ NEUTRAL POSITION SWITCH ASSEMBLY PNK WIRE PTC HTR 1 FUSE PTC HTR 2 FUSE PTC HTR 3 FUSE PTC HTR RELAY 1 PTC HTR RELAY 2 R/B 2 ASSEMBLY PTC HTR RELAY 3 R/B 2 ASSEMBLY R/B 4 ASSEMBLY (CENTER OF DASH) RED WIRE RIGHT END OF DASH) RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY S/HTR F/L FUSE S/HTR F/R FUSE S/HTR- MAIN FUSE STRG HTR FUSE STRG HTR RELAY TMC MADE TO ENGINE ROOM J/B 1 (DIAGRAM 4 OF 6) TO INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 3 OF 6) TO INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 4 OF 6) VIO WIRE W/ SEAT HEATER WHT WIRE WHT/BLK WIRE WIPER FUSE

A/C AMPLIFIER ASSEMBLY A/C UNIT ASSEMBLY AIR BAG SENSOR ASSEMBLY BLK WIRE BLK/RED WIRE BLU WIRE CENTER FRONT INSTRUMENT CLUSTER FINISH PANEL GARNISH CENTER REAR INSTRUMENT CLUSTER FINISH PANEL GARNISH COMBINATION METER ASSEMBLY DATA LINK CONNECTOR 3 DOME CUT RELAY DOME FUSE DOOR BACK FUSE DOOR BACK RELAY DOOR FUSE DOOR R/L FUSE DOOR R/R FUSE ECU-B 1 FUSE ECU-B 2 FUSE ELECTRIC PARKING BRAKE SWITCH ASSEMBLY FROM ACC RELAY (DIAGRAM 4 OF 6) FROM CERTIFICATION ECU (DIAGRAM 2 OF 6) FROM ENGINE ROOM R/B 1 (DIAGRAM 1 OF 6) FROM FUSIBLE LINK BLOCK ASSEMBLY (DIAGRAM 1 OF 6) FROM IGNITION/ STARTER SWITCH ASSEMBLY (DIAGRAM 2 OF 6) FRONT LUMBAR POWER SWITCH FRONT POWER SEAT SWITCH GRN WIRE GRY WIRE HAZ FUSE ID CODE BOX LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT INTERIOR ILLUMINATION LIGHT ASSEMBLY 1 LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LT BLU WIRE MAP LIGHT ASSEMBLY MIRROR (+) RELAY MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY NETWORK GATEWAY ECU OBD FUSE OCCUPANT DETECTION ECU P/SEAT FUSE PNK WIRE POWER FUSE R/B 4 ASSEMBLY (CENTER OF DASH) RED WIRE RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT INTERIOR ILLUMINATION LIGHT ASSEMBLY 1 RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY STEERING LOCK ACTUATOR ASSEMBLY (STEERING LOCK ACTUATOR/ UPPER BRACKET ASSEMBLY) STOP FUSE STOP LIGHT SWITCH ASSEMBLY STRG LOCK FUSE TELEMATICS TRANSCEIVER TMC MADE TO ACC RELAY (DIAGRAM 4 OF 6) TO CERTIFICATION ECU (DIAGRAM 2 OF 6) TO D/L FUSE (DIAGRAM 2 OF 6) TO ENGINE ROOM J/B 1 (DIAGRAM 1 OF 6) TO IGNITION/ STARTER SWITCH ASSEMBLY (DIAGRAM 2 OF 6) TRANSPONDER KEY ECU ASSEMBLY VIO WIRE W/ LUMBAR SUPPORT W/ RETRACTOR MIRROR W/O LUMBAR SUPPORT WHT WIRE WHT/BLK WIRE YEL WIRE

ACC RELAY BKUP LP FUSE BKUP LP RELAY BLK WIRE BLU WIRE DIODE (BACKUP) ECU-ACC FUSE ENGINE ROOM J/B 1 FAN RELAY 1 ENGINE ROOM R/B 1 FR FOG RELAY R/B 4 ASSEMBLY FROM CERTIFICATION ECU (DIAGRAM 2 OF 6) FROM ENGINE ROOM R/B 1 (DIAGRAM 2 OF 6) FROM IGNITION/ STARTER SWITCH ASSEMBLY (DIAGRAM 2 OF 6) FROM OBD FUSE (DIAGRAM 3 OF 6) GRN WIRE GRY WIRE HEADLIGHT LEVELING SWITCH LEFT HEADLIGHT ASSEMBLY LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LT BLU WIRE LT GRN WIRE LT GRN) GRN WIRE MAIN BODY ECU MAYDAY SWITCH ASSEMBLY MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY NETWORK GATEWAY ECU ORG/ WIRE OUTER MIRROR SWITCH ASSEMBLY P/OUTLET 1 FUSE P/OUTLET RELAY PANEL FUSE POWER OUTLET SOCKET ASSEMBLY 1 RADIO, DISPLAY RECEIVER ASSEMBLY REAR WIPER MOTOR ASSEMBLY RED WIRE RIGHT END OF DASH) RIGHT HEADLIGHT ASSEMBLY SFT LOCK- ACC FUSE SHIFT LOCK CONTROL UNIT ASSEMBLY SHIFT POSITION INDICATOR TAIL FUSE TAIL RELAY TMC MADE VIO WIRE WASHER FUSE WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER MOTOR ASSEMBLY WINDSHIELD WIPER RELAY ASSEMBLY WINDSHIELD WIPER SWITCH ASSEMBLY WIPER RR FUSE

A/C AMPLIFIER ASSEMBLY A/C CONTROL ASSEMBLY A/C UNIT ASSEMBLY BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY CLOCK ASSEMBLY COMPRESSOR W/ PULLEY ASSEMBLY DEF RELAY ENGINE ROOM R/B 1 DEICER RELAY FORWARD RECOGNITION CAMERA FORWARD RECOGNITION HOOD INNER REAR VIEW MIRROR ASSEMBLY INSTRUMENT PANEL J/B ASSEMBLY ION GENERATOR SUB-ASSEMBLY LEFT "C" PILLAR) LEFT BLIND SPOT MONITOR SENSOR LEFT HEADLIGHT ECU SUB-ASSEMBLY LT BLU WIRE LT GRN WIRE MAIN BODY ECU MILLIMETER WAVE RADAR SENSOR ASSEMBLY NETWORK GATEWAY ECU NOT USED ORG/ WIRE POWER STEERING ECU ASSEMBLY PRE-COLLISION CITY BUZZER PTC HTR 1 RELAY PTC HTR 2 RELAY PTC HTR 3 RELAY R/B 2 ASSEMBLY RADIO, DISPLAY RECEIVER ASSEMBLY RAIN SENSOR REAR CROSS TRAFFIC ALERT BUZZER (BLIND SPOT MONITOR BUZZER) RED WIRE RIGHT BLIND SPOT MONITOR SENSOR RIGHT HEADLIGHT ECU SUB-ASSEMBLY STEERING HEATER SWITCH STEERING SENSOR TMC MADE TO R/B 2 ASSEMBLY (DIAGRAM 2 OF 6) VIO WIRE W/ LED WINDSHIELD WIPER RELAY ASSEMBLY

A/C CONTROL ASSEMBLY AUTO HIGH BEAM SWITCH BLK WIRE BLU WIRE CLOCK ASSEMBLY DOOR CONTROL SWITCH ASSEMBLY ELECTRIC PARKING BRAKE SWITCH ASSEMBLY FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 4 OF 6) FUEL LID OPENER SWITCH GLOVE BOX LIGHT ASSEMBLY GRN WIRE HAZARD WARNING SIGNAL SWITCH ASSEMBLY LEFT "C" PILLAR) LEFT LICENSE PLATE LIGHT ASSEMBLY LEFT REAR COMBINATION LIGHT ASSEMBLY MAP LIGHT ASSEMBLY PNK WIRE RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE RIGHT END OF DASH) RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT LICENSE PLATE LIGHT ASSEMBLY RIGHT REAR COMBINATION LIGHT ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY SHIFT POSITION INDICATOR SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY STEERING HEATER SWITCH STEERING PAD SWITCH ASSEMBLY TMC MADE VIO WIRE W/ TELEMATICS SYSTEM W/O TELEMATICS SYSTEM WHT WIRE
