Courtesy lamps circuit for Toyota bZ4X I (2022-2024)

BLK WIRE BLU WIRE BRN WIRE CANH 1 5 CANL COMPUTER DATA LINES SYSTEM CTYL DOME CUT RELAY ECU-DCC 2 FUSE ECU-IGR 2 FUSE FSPT GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGR 2 RELAY ENERGIZED IGR INP STD 2 FUSE LCTY LEFT FRONT DOOR ARMREST ILLUMINATION LIGHT LEFT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT REAR DOOR ARMREST ILLUMINATION LIGHT LEFT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY LEFT REAR FOOT LIGHT (INTERIOR ILLUMINATION LIGHT SUB-ASSEMBLY) LT BLU WIRE LT GRN WIRE MAIN BODY ECU (LEFT SIDE OF DASH) MILE MLP MOTOR COMPARTMENT R/B 1 ORG/ WIRE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/GRN WIRE PPL/RED WIRE PPL/VIO WIRE RCTY RED WIRE RIGHT END OF DASH) RIGHT FRONT DOOR ARMREST ILLUMINATION LIGHT RIGHT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY RIGHT OUTER REAR VIEW MIRROR ASSEMBLY RIGHT REAR DOOR ARMREST ILLUMINATION LIGHT RIGHT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY RIGHT REAR FOOT LIGHT (INTERIOR ILLUMINATION LIGHT SUB-ASSEMBLY) VIO WIRE W/ DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY W/O PANORAMIC VIEW MONITOR SYSTEM WHT WIRE WHT/BLK WIRE

BACK DOOR LOCK W/ COURTESY LIGHT SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE CTY CTYO CTYR DOME FUSE DOOR CONTROL SWITCH (W/ POWER BACK DOOR) GRN WIRE GRY WIRE HOT AT ALL TIMES INTERIOR ILLUMINATION LIGHT ASSEMBLY 1 KA (UNDER CENTER CONSOLE) KB (BASE OF RIGHT "B" PILLAR) LEFT CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY LEFT FRONT FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 2) LEFT OUTER REAR VIEW MIRROR ASSEMBLY LEFT VANITY LIGHT ASSEMBLY LEFT VISOR ASSEMBLY LT BLU WIRE LT GRN WIRE LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1 MAP LIGHT ASSEMBLY MLP MULTIPLEX NETWORK DOOR ECU ORG/ WIRE PNK WIRE POWER BACK DOOR CONTROL SWITCH 1 POWER DISTRIBUTION BOX ASSEMBLY PPL/BLK WIRE PPL/RED WIRE PPL/WHT WIRE RED WIRE RIGHT CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY RIGHT END OF DASH) RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT FRONT FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1) RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY RIGHT VANITY LIGHT ASSEMBLY RIGHT VISOR ASSEMBLY RLMP ROOM LIGHT ASSEMBLY 1 SLPD TELEMATICS TRANSCEIVER VIO WIRE W/ DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY W/O PANORAMIC VIEW MONITOR SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE
