Toyota bZ4X I (2022-2024) Ground distribution circuit

AIR CONDITIONING AMPLIFIER ASSEMBLY AIR CONDITIONING CONTROL ASSEMBLY AUTO HIGH BEAM SWITCH BLE INDOOR DIGITAL KEY RECEIVER ASSEMBLY BRAKE CONTROL POWER SUPPLY ASSEMBLY CAN JUNCTION TERMINAL 2 CERTIFICATION ECU COMBINATION SWITCH ASSEMBLY ELECTRIC CONVERTER UNIT ASSEMBLY SHIELD ELECTRIC PARKING BRAKE SWITCH ASSEMBLY EV SUPPLY BATTERY ASSEMBLY HAZARD WARNING SIGNAL SWITCH ASSEMBLY HEATER MANAGEMENT ECU ASSEMBLY HYBRID VEHICLE CONTROL ECU ID CODE BOX INTEGRATION CONTROL SUPPLY LEFT USB CHARGER SOCKET LEVEL WARNING SWITCH ASSEMBLY MILLIMETER WAVE RADAR SENSOR ASSEMBLY MOBILE WIRELESS CHARGER CRADLE ASSEMBLY NETWORK GATEWAY ECU POWER BACK DOOR CONTROL SWITCH POWER OUTLET SOCKET ASSEMBLY 1 PPL RADIATOR SHUTTER ASSEMBLY RADIO, DISPLAY RECEIVER ASSEMBLY RIGHT HEADLIGHT ECU SUB-ASSEMBLY RIGHT QUICK HEATER, ACCESSORY ASSEMBLY RIGHT USB CHARGER SOCKET SHIELD STEERING SENSOR STEREO COMPONENT AMPLIFIER ASSEMBLY TELEMATICS TRANSCEIVER TRANSMISSION FLOOR SHIFT ASSEMBLY VEHICLE APPROACHING SPEAKER CONTROLLER WHT/BLK WIRE WINDSHIELD GLASS

A/C MAIN RELAY A/C RELAY ACC RELAY 2 BLK WIRE BRAKE LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY) BRN WIRE CHARGE INLET CHARGER INLET COMMUNICATION ECU COMPRESSOR W/ MOTOR ASSEMBLY ELECTRIC CONVERTER UNIT ASSEMBLY ELECTRIC HEATER SUB-ASSEMBLY FR OIL PMP RELAY FRONT EV MOTOR CONTROL INVERTER ASSEMBLY FRONT OIL PUMP MOTOR GRN WIRE HOOD COURTESY SWITCH (HOOD LOCK ASSEMBLY) IGCT SCENE RELAY IGCT-IG RELAY 1 IGCT-IG RELAY 2 IGP RELAY 1 IGP RELAY 2 INV W/P RELAY LEFT CHARGE INLET BOX ASSEMBLY LEFT HEADLIGHT ECU SUB-ASSEMBLY PLUG LOCK RELAY 1 PLUG LOCK RELAY 2 PPL RED WIRE RESISTOR RR OIL PMP RELAY SEMICONDUCTOR POWER INTEGRATION ECU SHIFT CONTROL ACTUATOR ASSEMBLY W/ STEERING HEATER WATER PUMP W/ MOTOR ASSEMBLY WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER MOTOR ASSEMBLY WIPER RELAY

AIR BAG SENSOR ASSEMBLY ALL DOOR LOCK RELAY BATTERY BLK WIRE BLK/GRY WIRE BLOWER MOTOR W/ FAN SUB-ASSEMBLY BRAKE BOOSTER CONTROL ECU (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY) BRN WIRE COMBINATION METER ASSEMBLY D DOOR UNLOCK RELAY DOOR BACK RELAY FORWARD RECOGNITION CAMERA FRONT WASHER NOZZLE, HOSE ASSEMBLY HEATER PUMP ASSEMBLY HYBRID VEHICLE CONTROL ECU INNER REAR VIEW MIRROR ASSEMBLY L/D DOOR UNLOCK RELAY LEFT QUICK HEATER, ACCESSORY ASSEMBLY LEFT VISOR ASSEMBLY MAIN BODY ECU MAP LIGHT ASSEMBLY P/OUTLET RELAY PPL RAIN SENSOR RIGHT VISOR ASSEMBLY ROOM LIGHT ASSEMBLY 1 RR DEF RELAY SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY) SPIRAL CABLE SUB-ASSEMBLY STOP LIGHT SWITCH ASSEMBLY W/ DIGITAL INNER MIRROR W/O DIGITAL INNER MIRROR WATER PUMP W/ MOTOR ASSEMBLY WHT/BLK WIRE WINDSHIELD WIPER RELAY ASSEMBLY

COMMUNICATION ECU DOOR CONTROL SWITCH ASSEMBLY FAN W/ MOTOR ASSEMBLY LEFT BLE INDOOR DIGITAL KEY RECEIVER ASSEMBLY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT FRONT POWER SEAT SWITCH LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT FRONT SEAT CUSHION HEATER (LEFT FRONT SEAT CUSHION PAD) LEFT FRONT SEAT INNER BELT ASSEMBLY LEFT OUTER REAR VIEW MIRROR ASSEMBLY LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LEFT SEAT CUSHION CLIMATE CONTROL CONTROL ASSEMBLY (LEFT FRONT SEAT) LEFT USB CHARGER SOCKET 2 MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY OUTER MIRROR SWITCH ASSEMBLY PARKING ASSIST ECU POWER STEERING ECU (RACK, PINION POWER STEERING GEAR ASSEMBLY) PPL REAR SEAT HEATER SWITCH RIGHT END OF DASH) RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT FRONT SEAT CUSHION HEATER (RIGHT FRONT SEAT CUSHION PAD) RIGHT OUTER REAR VIEW MIRROR ASSEMBLY RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY (RIGHT FRONT SEAT) RIGHT USB CHARGER SOCKET 2 W/ CLIMATE CONTROL SEAT W/ PANORAMIC VIEW MONITOR SYSTEM W/O PANORAMIC VIEW MONITOR SYSTEM W/ POWER SEAT WHT WIRE WHT/BLK WIRE

BACK DOOR LOCK W/ COURTESY LIGHT SWITCH ASSEMBLY BACK DOOR OPENER SWITCH ASSEMBLY BLE DOOR DIGITAL KEY RECEIVER ASSEMBLY BLK WIRE CAN JUNCTION TERMINAL 3 CAN JUNCTION TERMINAL 5 CENTER STOP LIGHT ASSEMBLY CLEARANCE WARNING ECU ASSEMBLY DIGITAL KEY ECU ASSEMBLY DOOR CONTROL SWITCH ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY KICK DOOR CONTROL SENSOR LEFT BLIND SPOT MONITOR SENSOR LEFT REAR COMBINATION LIGHT ASSEMBLY LEFT REAR SEAT CUSHION PAD LEFT REAR SEAT INNER BELT W/ CENTER ASSEMBLY MULTIPLEX NETWORK DOOR ECU POWER BACK DOOR CONTROL SWITCH 1 POWER BACK DOOR WARNING BUZZER PPL REAR LIGHT ASSEMBLY REAR OIL PUMP MOTOR REAR TRANSAXLE W/ MOTOR, INVERTER ASSEMBLY REAR WINDOW DEFOGGER (BACK DOOR GLASS) RIGHT BLE INDOOR DIGITAL KEY RECEIVER ASSEMBLY RIGHT BLIND SPOT MONITOR SENSOR RIGHT LICENSE PLATE LIGHT ASSEMBLY RIGHT REAR COMBINATION LIGHT ASSEMBLY RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT REAR SEAT CUSHION PAD RIGHT REAR SEAT INNER BELT ASSEMBLY WHT WIRE WHT/BLK WIRE
