Toyota bZ4X I (2022-2024) wsh nzl htr relay motor compartment r/b 1 Wiring diagram

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIS ECU-ACC FUSE ECU-IGR 2 FUSE ECU-IGR 5 FUSE EPS-IGR FUSE FORWARD RECOGNITION CAMERA FROM ACC RELAY (DIAGRAM 4 OF 8) FROM CERTIFICATION ECU (DIAGRAM 8 OF 8) FROM IGR 2 RELAY (DIAGRAM 4 OF 8) FROM P/OUTLET RELAY (DIAGRAM 4 OF 8) GRN WIRE GRY WIRE HYBRID VEHICLE CONTROL ECU INNER REAR VIEW MIRROR ASSEMBLY INTEGRATION CONTROL SUPPLY LEFT HEADLIGHT ECU SUB-ASSEMBLY LEFT USB CHARGER SOCKET LT BLU WIRE LT GRN WIRE MAIN BODY ECU MAP LIGHT ASSEMBLY MILLIMETER WAVE RADAR SENSOR ASSEMBLY MOBILE WIRELESS CHARGER CRADLE ASSEMBLY NETWORK GATEWAY ECU ORG/ WIRE OUTER MIRROR SWITCH ASSEMBLY P/OUTLET 1 FUSE PNK WIRE POWER OUTLET SOCKET ASSEMBLY 1 POWER STEERING ECU (RACK, PINION POWER STEERING GEAR ASSEMBLY) PPL/LT GRN WIRE RADIO, DISPLAY RECEIVER ASSEMBLY RAIN SENSOR RED WIRE RIGHT HEADLIGHT ECU SUB-ASSEMBLY RIGHT USB CHARGER SOCKET TELEMATICS TRANSCEIVER TO MOTOR COMPARTMENT R/B 1 (DIAGRAM 3 OF 8) TO OPTION CONNECTOR (DIAGRAM 4 OF 8) TO P/OUTLET RELAY (DIAGRAM 4 OF 8) USB 1 FUSE USB 2 FUSE VIO WIRE WHT WIRE WHT/BLK WIRE WSH NZL HTR RELAY MOTOR COMPARTMENT R/B 1
