Toyota bZ4X I (2022-2024) windshield wiper switch assembly Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper switch assembly, which is found in the car Toyota bZ4X I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper switch assembly (1 of 1)
+SM
-WR
AK (LEFT SIDE OF DASH)
AUTO
BLK WIRE
BLU WIRE
CAMERA WASHER +
COMPUTER DATA LINES SYSTEM
ECU- DC/DC FUSE
EWS
FR WASH
FRONT WASHER NOZZLE, HOSE ASSEMBLY
FRONT, CAMERA WASHER SWITCH
GRN WIRE
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
IGWS
INTERMITTENT
LT BLU WIRE
LT GRN WIRE
MIST
MOTOR COMPARTMENT R/B 1
OFF
ORG/ WIRE
RED WIRE
STEERING SENSOR
STEERING WHEEL SWITCH HOUSING
VIO WIRE
VOLUME SWITCH (W/O AUTO WIPER)
W-OFF
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY
WINDSHIELD WIPER RELAY ASSEMBLY
WINDSHIELD WIPER SWITCH ASSEMBLY
WIPER FUSE
WIPER RELAY
WIPER SWITCH
WSH NZL HTR RELAY
Go to component -> Wiper/washer circuit (1 of 2) -> WINDSHIELD WIPER SWITCH ASSEMBLY
