Toyota bZ4X I (2022-2024) w/ panorama roof Wiring diagram
This page shows the only wiring diagram for the component.w/ panorama roof, which is found in the car Toyota bZ4X I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ panorama roof (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CANN
CANP
CAPH
CAPL
CLEARANCE WARNING ECU ASSEMBLY
GRN WIRE
GRY WIRE
INNER REAR VIEW MIRROR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
MULTIPLEX NETWORK DOOR ECU
PNK WIRE
RED WIRE
RIGHT BLIND SPOT MONITOR SENSOR
VIO WIRE
W/ PANORAMA ROOF
WHT WIRE
Go to component -> Computer data lines circuit (2 of 7) -> W/ PANORAMA ROOF
