Toyota bZ4X I (2022-2024) ose ppl/pnk Wiring diagram
This page shows the only wiring diagram for the component.ose ppl/pnk, which is found in the car Toyota bZ4X I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ose ppl/pnk (1 of 1)
BACK DOOR LOCK W/ COURTESY LIGHT SWITCH ASSEMBLY
BD+2
BD-
BD-2
BDDN
BLK WIRE
BLU WIRE
BZR
CANN
CANP
CLS
COMPUTER DATA LINES SYSTEM
CTY
CTYO
DC-
DSG
DSV
ECU-DCC 2 FUSE
ECU-IGR 1 FUSE
ECU-IGR 2 FUSE
ECUB
FA (LEFT CENTER OF DASH)
FSW+
FUL PNK CLSW WIRE
GRN WIRE
GRY WIRE
HAF
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
HOT W/ IGR 2 RELAY ENERGIZED
IGR
LEFT POWER BACK DOOR UNIT ASSEMBLY SET
LIB
LSBO
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MOTOR COMPARTMENT R/B 1
MULTIPLEX NETWORK DOOR ECU
OPN
OSE PPL/PNK WIRE
OSL
OSR
PAWL
PBD FUSE
PBDS
PNK WIRE
POS
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/WHT WIRE
RED WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Back door opener circuit, w/ power back door (1 of 3) -> OSE PPL/PNK WIRE
