Toyota bZ4X I (2022-2024) mirror adjust switch Wiring diagram
This page shows the only wiring diagram for the component.mirror adjust switch, which is found in the car Toyota bZ4X I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror adjust switch (1 of 1)
BLINDSPOT MONITOR INDICATOR
BLK WIRE
BLK/RED WIRE
BLU WIRE
BSL+
BTL
DEFOGGER SYSTEM
DOWN
DOWN RIGHT
GRN WIRE
GRY WIRE
GTL
LEFT
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
M+ VL
MIRROR ADJUST SWITCH
MIRROR HEATER
MLP
MV M+
NAVIGATION SYSTEM
ORG/ WIRE
OUTER MIRROR SWITCH ASSEMBLY
PARKING ASSIST LIGHT
PNK WIRE
PPL
PPL PNK WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT GRN WIRE
PPL/ORG WIRE
PPL/RED WIRE
RED WIRE
RIGHT
SELECT SWITCH
UP LEFT
VIO WIRE
W/O PANORAMIC VIEW MONITOR SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Power mirrors circuit (1 of 2) -> MIRROR ADJUST SWITCH
