Toyota bZ4X I (2022-2024) left steering switch steering pad switch assembly Wiring diagram
This page shows the only wiring diagram for the component.left steering switch steering pad switch assembly, which is found in the car Toyota bZ4X I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left steering switch steering pad switch assembly (1 of 1)
AIR CONDITIONING CONTROL ASSEMBLY
BLK WIRE
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
GRN WIRE
GRY WIRE
HAZARD WARNING SIGNAL SWITCH ASSEMBLY
IL+2
IL-2
LEFT STEERING SWITCH STEERING PAD SWITCH ASSEMBLY
LIL+
LT BLU WIRE
MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
ORG/ WIRE
OUTER MIRROR SWITCH ASSEMBLY
PNK WIRE
RED WIRE
RIGHT STEERING SWITCH
SPIRAL CABLE SUB-ASSEMBLY
TAIL
VIO WIRE
WHT WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> LEFT STEERING SWITCH STEERING PAD SWITCH ASSEMBLY
