Toyota bZ4X I (2022-2024) left console box illumination light assembly Wiring diagrams
This page contains all the electrical diagrams for the component. left console box illumination light assembly, in which he is found in the car Toyota bZ4X I (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left console box illumination light assembly (1 of 2)
BACK DOOR LOCK W/ COURTESY LIGHT SWITCH ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
CTY
CTYO
CTYR
DOME FUSE
DOOR CONTROL SWITCH (W/ POWER BACK DOOR)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERIOR ILLUMINATION LIGHT ASSEMBLY 1
KA (UNDER CENTER CONSOLE)
KB (BASE OF RIGHT "B" PILLAR)
LEFT CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
LEFT FRONT FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 2)
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LEFT VANITY LIGHT ASSEMBLY
LEFT VISOR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1
MAP LIGHT ASSEMBLY
MLP
MULTIPLEX NETWORK DOOR ECU
ORG/ WIRE
PNK WIRE
POWER BACK DOOR CONTROL SWITCH 1
POWER DISTRIBUTION BOX ASSEMBLY
PPL/BLK WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
RIGHT CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
RIGHT END OF DASH)
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT FRONT FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT VANITY LIGHT ASSEMBLY
RIGHT VISOR ASSEMBLY
RLMP
ROOM LIGHT ASSEMBLY 1
SLPD
TELEMATICS TRANSCEIVER
VIO WIRE
W/ DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
W/O PANORAMIC VIEW MONITOR SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LEFT CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
Wiring diagram left console box illumination light assembly (2 of 2)
ACCD
BLK WIRE
BLU WIRE
BRN WIRE
CERTIFICATION ECU
FROM POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 4 OF 8)
FROM POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 5 OF 8)
GRN WIRE
GRY WIRE
IGPD
IGRD
INTERIOR ILLUMINATION LIGHT ASSEMBLY 1
LEFT CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
LEFT FRONT DOOR ARMREST ILLUMINATION LIGHT
LEFT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
LEFT FRONT FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 2)
LEFT REAR DOOR ARMREST ILLUMINATION LIGHT
LEFT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
LEFT REAR FOOT LIGHT (INTERIOR ILLUMINATION LIGHT SUB-ASSEMBLY)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
POWER SWITCH
PPL/BLK WIRE
PPL/VIO WIRE
RED WIRE
RIGHT CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
RIGHT END OF DASH)
RIGHT FRONT DOOR ARMREST ILLUMINATION LIGHT
RIGHT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
RIGHT FRONT FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
RIGHT REAR DOOR ARMREST ILLUMINATION LIGHT
RIGHT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
RIGHT REAR FOOT LIGHT (INTERIOR ILLUMINATION LIGHT SUB-ASSEMBLY)
SHORT CONNECTOR 1
SHORT CONNECTOR 2
TO MOBILE WIRELESS CHARGER CRADLE ASSEMBLY (DIAGRAM 7 OF 8)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 3 OF 8)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 4 OF 8)
VIO WIRE
WCSW
Go to component -> Power distribution circuit (8 of 8) -> LEFT CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
