Wiring diagram capacitor fuse (1 of 2)
+BC
ABS 1 FUSE
ABS 2 FUSE
ABS MTR FUSE
ABS- MAIN FUSE
BLK WIRE
BLU WIRE
BRAKE BOOSTER CONTROL ECU (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY)
BRAKE CONTROL POWER SUPPLY ASSEMBLY
BRAKE LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
BRN WIRE
CAPACITOR FUSE
CBKP
CLIN
COMPUTER DATA LINES SYSTEM
CTY
CWKP
ECU- IGP 2 FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
IGR
INTEGRATION CONTROL SUPPLY
LBL
LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MOTOR COMPARTMENT R/B 1
OUT
PNK WIRE
SBIN
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WKUP
Go to component -> Anti-lock brakes circuit (1 of 3) -> CAPACITOR FUSE
Wiring diagram capacitor fuse (2 of 2)
ABS 1 FUSE
ABS 2 FUSE
ABS MTR FUSE
ABS- MAIN FUSE
BATT-S 1 FUSE
BATT-S 2 FUSE
BATTERY
BATTERY STATE SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE BOOSTER CONTROL ECU (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY)
BRAKE CONTROL POWER SUPPLY ASSEMBLY
CAPACITOR FUSE
DC/DC FUSE
DK GRN WIRE
ELECTRIC CONVERTER UNIT ASSEMBLY
EPS-1 FUSE
FRONT EV MOTOR CONTROL INVERTER ASSEMBLY
FUSIBLE LINK BLOCK ASSEMBLY
G/SHUTTER FUSE
GRN WIRE
HYBRID VEHICLE CONTROL ECU
IGCT 4 FUSE
IGCT- IG 1 FUSE
IGCT-IG 1 RELAY
IGCT-IG 2 RELAY
IGP- MAIN 2 FUSE
INP STD 1 FUSE
INP STD 2 FUSE
LEFT CHARGE INLET BOX ASSEMBLY
LT BLU WIRE
MAIN FUSE
MOTOR COMPARTMENT J/B 1
ORG/ WIRE
PCU FR FUSE
PCU RR FUSE
POWER DISTRIBUTION BOX ASSEMBLY
POWER STEERING ECU (RACK, PINION POWER STEERING GEAR ASSEMBLY)
PPL/WHT WIRE
RADIATOR SHUTTER ASSEMBLY
RADIO FUSE
RADIO, DISPLAY RECEIVER ASSEMBLY
REAR TRANSAXLE W/ MOTOR, INVERTER ASSEMBLY
RED WIRE
SEMICONDUCTOR POWER INTEGRATION ECU
SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)
STD PI 1 FUSE
TO FUSE IGCT-SCENE (DIAGRAM 2 OF 8)
TO MOTOR COMPARTMENT R/B 1 (DIAGRAM 3 OF 8)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 5 OF 8)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Power distribution circuit (1 of 8) -> CAPACITOR FUSE
