Wiper/washer circuit for Toyota Avalon XX50 (2018-2024)
Wiper/washer circuit (1 of 2)
AUTO
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
EXCEPT HYBRID
GRN WIRE
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
INTERMITTENT TIME ADJUSTMENT SWITCH
LIN
LT BLU WIRE
LT GRN WIRE
MIST
OFF
ORG/ WIRE
PPL
RED WIRE
RELAY ENERGIZED
STEERING SENSOR
W-OFF
WASHER FUSE
WASHER RELAY
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY
WINDSHIELD WIPER MOTOR ASSEMBLY
WINDSHIELD WIPER SWITCH
WIPER FUSE
WIPER RELAY
WIPER SWITCH
Wiper/washer circuit (2 of 2)
BLK WIRE
BLU WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CONTROL
ECU-ACC FUSE
ECU-DCC 2 FUSE
FWSR
GE (LEFT END OF DASH)
GF (LEFT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LEVEL WARNING SWITCH ASSEMBLY (WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY)
LIN
LT GRN WIRE
MPX
MULTIPLEX NETWORK BODY ECU (LEFT END OF DASH)
ORG/ WIRE
PPL/BLU WIRE
RAIN SENSOR (AIR CONDITIONING THERMISTOR ASSEMBLY)
RED WIRE
RELAY ENERGIZED
SIG
STANDARD
UNIT)
WHT WIRE
WHT/BLK WIRE
WPS
