3.5l, transmission circuit for Toyota Avalon XX50 (2018-2024)
3.5l, transmission circuit (1 of 3)
ACCELERATOR PEDAL SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EFI MAIN 2 RELAY
EFI- MAIN 1 FUSE
EFI- MAIN 1 RELAY
EFI- MAIN 3 RELAY
ELECTRONICALLY CONTROLLED TRANSMISSION SOLENOID (TRANSMISSION WIRE)
ENGINE CONTROLS SYSTEM
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
NCB
NCO
NTB
NTO
O/T
ORG/ WIRE
PNK WIRE
PPL/GRY WIRE
RED WIRE
SFTD
SFTU
SLT-
SLU+
VIO WIRE
WHT WIRE
WHT/BLK WIRE
3.5l, transmission circuit (2 of 3)
BKUP LP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CAN STANDARD I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DIODE (RIGHT KICK PANEL)
ECU-ACC FUSE
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/ORG WIRE
PPL/PNK WIRE
PWR
RED WIRE
RELAY ENERGIZED
SHIFT POSITION INDICATOR
STARTING/ CHARGING SYSTEM
THROTTLE W/ MOTOR BODY ASSEMBLY (RIGHT REAR OF ENGINE)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
3.5l, transmission circuit (3 of 3)
BKUP LP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CC (LEFT SIDE OF ENGINE)
DIODE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LEFT SIDE SHIFT DOWN SWITCH
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL/PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT SIDE SHIFT UP SWITCH
SDN
SFTD
SFTU
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY (TOP OF BRAKE PEDAL ASSEMBLY)
SUP
W/O PADDLE SHIFT
WHT WIRE
WHT/BLK WIRE
