Shift interlock circuit, hybrid for Toyota Avalon XX50 (2018-2024)
Shift interlock circuit, hybrid
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECU-ACC FUSE
GRN WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ ACC RELAY ENERGIZED
HOT W/ IGCT RELAY ENERGIZED
HYBRID VEHICLE CONTROL ECU
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
P POSITION DETECTION SWITCH
PLKC
PM IGCT FUSE
PNK WIRE
PPL/GRN WIRE
PSFT
RED WIRE
RELAY BLOCK 4 (LEFT KICK PANEL)
SFTD
SFTU
SHIFT LEVER POSITION SENSOR
SHIFT LOCK CONTROL UNIT ASSEMBLY (UNDER CENTER FLOOR CONSOLE)
SHIFT LOCK SOLENOID
SMART KEY ECU ASSEMBLY
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY (TOP OF BRAKE PEDAL ASSEMBLY)
TRANSMISSIONS SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
