Power top/sunroof circuit for Toyota Avalon XX50 (2018-2024)
Power top/sunroof circuit
BLK WIRE
BLU WIRE
CLS
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DOWN
DWN
ECU-ACC FUSE
ECU-DCC 2 FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
IG PPL/PNK WIRE
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAIN BOARD
MULTIPLEX NETWORK BODY ECU
OPN
ORG/ WIRE
PNK WIRE
PPL
PPL/BLU WIRE
PPL/GRY WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
ROOF CONSOLE
ROOF CONSOLE BOX ASSEMBLY
S/ROOF FUSE
SLIDE CLOSE SLIDE OPEN
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY)
TILT DOWN
TILT UP
WHT WIRE
WHT/BLK WIRE
