Front heated seats circuit, w/ climate control seat for Toyota Avalon XX50 (2018-2024)
Front heated seats circuit, w/ climate control seat (1 of 2)
BLK WIRE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LEFT FRONT SEAT CUSHION HEATER ASSEMBLY
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK SWL WIRE
PNK WIRE
PPL/BLK WIRE
PPL/RED WIRE
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
REFRESHING SEAT SWITCH
RELAY BLOCK 3
RELAY BLOCK 4
RELAY ENERGIZED
S/HTR F/L FUSE
S/HTR F/R FUSE
S/HTR F/R RELAY
S/HTR- MAIN FUSE
SEAT BACK HEATER
SEAT CUSHION HEATER
THL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Front heated seats circuit, w/ climate control seat (2 of 2)
AIR CONDITIONING AMPLIFIER ASSEMBLY (BEHIND LEFT CENTER OF DASH)
BBS
BFB-
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
CTB
GRN WIRE
KA (CENTER REAR OF ROOF)
LEFT SEAT BACK CLIMATE CONTROL BLOWER
LEFT SEAT CUSHION CLIMATE CONTROL BLOWER
LOUT
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT SEAT CUSHION HEATER ASSEMBLY
RIGHT SEAT BACK CLIMATE CONTROL BLOWER
RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER
ROUT
SEAT BACK HEATER
SEAT CUSHION HEATER
SG-5
SG-6
SHD
SHP+
SIGN
SWR
THR+
TSL
TSR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
