Power mirrors circuit for Toyota Avalon XX50 (2018-2024)
Power mirrors circuit
BLIND SPOT MONITOR
BLU WIRE
BRN WIRE
BSL+
BSR+
DEFOGGER SYSTEM
DOWN
EC+
ECU-ACC FUSE
ELECTROCHROMIC MIRROR CIRCUIT
EXTERIOR LIGHTS, DEFOGGER, NAVIGATION SYSTEMS
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LEFT
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MIRROR HEATER
NAVIGATION SYSTEM
ORG/ WIRE
OUTER MIRROR SWITCH ASSEMBLY
PNK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/VIO WIRE
RED WIRE
RIGHT
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
TURN
UP/LEFT
WHT/BLK WIRE
YEL WIRE
