Cooling fan circuit, except hybrid for Toyota Avalon XX50 (2018-2024)

Cooling fan circuit, except hybrid

Get access

2.5L 3.5L BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM EFI 2 FUSE ENGINE COOLANT TEMPERATURE SENSOR ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1 ENGINE ROOM RELAY BLOCK ASSEMBLY 1 FAN 1 FUSE FAN W/ MOTOR ASSEMBLY HOT AT ALL TIMES HOT W/ EFI-MAIN 1 RELAY ENERGIZED LT GRN WIRE RFC VIO WIRE WHT WIRE WHT/BLK WIRE
