Toyota Avalon XX50 (2018-2024) relay block 4 Wiring diagrams

This page contains all the electrical diagrams for the component. relay block 4, in which he is found in the car Toyota Avalon XX50 (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

relay block 4 wiring diagram (1 of 5)

ACCELERATOR PEDAL SENSOR ASSEMBLY BLK WIRE BLU WIRE BRN WIRE DBI ENGINE CONTROLS SYSTEM ETTA EVSW GCS GCSG GMT GMTG GNT GRF GRFG GRN WIRE GRY WIRE GSN GSNG HMCH HMCL HSDN HYBRID VEHICLE CONTROL ECU HYBRID VEHICLE TRANSAXLE ASSEMBLY IGCT 2 FUSE IGCT RELAY INDD INDM INDN INDP INDR LT BLU WIRE LT GRN WIRE MCS MCSG MMT MMTG MRF MRFG MSN MSNG NORM ORG/ WIRE PCU FUSE PM IGCT FUSE PNB PNK WIRE PPL/GRN WIRE PSFT RED WIRE RELAY BLOCK 3 RELAY BLOCK 4 SFTD SFTU SHIELD SPRT TTA VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> 2.5l hybrid, transmission circuit (1 of 4) -> RELAY BLOCK 4

relay block 4 wiring diagram (2 of 5)

BATT FAN FUSE BATTERY COMPUTER ASSEMBLY BATTERY COOLING BLOWER ASSEMBLY BLK WIRE BLU WIRE HOT W/ IGCT RELAY ENERGIZED HV SUPPLY BATTERY ASSEMBLY LT GRN WIRE PNK/BLK WIRE RED WIRE RELAY BLOCK 4 VIO WIRE WHT/BLK WIRE

Go to component -> Battery cooling fan circuit -> RELAY BLOCK 4

relay block 4 wiring diagram (3 of 5)

BLK WIRE ENGINE ROOM RELAY BLOCK ASSEMBLY 1 GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY LEFT FRONT SEAT CUSHION HEATER ASSEMBLY LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK SWL WIRE PNK WIRE PPL/BLK WIRE PPL/RED WIRE RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE REFRESHING SEAT SWITCH RELAY BLOCK 3 RELAY BLOCK 4 RELAY ENERGIZED S/HTR F/L FUSE S/HTR F/R FUSE S/HTR F/R RELAY S/HTR- MAIN FUSE SEAT BACK HEATER SEAT CUSHION HEATER THL VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Front heated seats circuit, w/ climate control seat (1 of 2) -> RELAY BLOCK 4

relay block 4 wiring diagram (4 of 5)

AIR CONDITIONING AMPLIFIER ASSEMBLY (BEHIND LEFT CENTER OF DASH) BLK WIRE BLU WIRE ENGINE ROOM RELAY BLOCK ASSEMBLY 1 GRN WIRE GRY WIRE HOT AT ALL TIMES IGN INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY LEFT FRONT SEAT CUSHION HEATER ASSEMBLY LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL/BLK WIRE PPL/RED WIRE RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE RELAY BLOCK 3 RELAY BLOCK 4 RELAY ENERGIZED RIGHT FRONT SEAT CUSHION HEATER ASSEMBLY S/HTR F/L FUSE S/HTR F/R FUSE S/HTR F/R RELAY S/HTR- MAIN FUSE SEAT BACK HEATER SEAT CUSHION HEATER SEAT HEATER SWITCH SG-5 SG-6 SHD SHP+ SWL SWR THL THR+ TSL TSR VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Front heated seats circuit, w/o climate control seat -> RELAY BLOCK 4

relay block 4 wiring diagram (5 of 5)

ACCELERATOR PEDAL SENSOR ASSEMBLY ACCI BATT FAN FUSE BLK WIRE BLU WIRE BRN WIRE ETTA GCS GCSG GMT GMTG GRF GRFG GRN WIRE GRY WIRE GSN GSNG HYBRID VEHICLE CONTROL ECU HYBRID VEHICLE TRANSAXLE ASSEMBLY IGCT 2 FUSE IGCT RELAY INV W/PMP FUSE IWP LT BLU WIRE LT GRN WIRE MCS MCSG MMT MMTG MRF MRFG MSN MSNG NIWP ORG/ WIRE PCU FUSE PM IGCT FUSE PNK WIRE PPL/GRN WIRE RED WIRE RELAY BLOCK 3 RELAY BLOCK 4 SHIELD TTA VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 2.5l hybrid, hybrid system circuit (1 of 8) -> RELAY BLOCK 4

Toyota Avalon XX50 (2018-2024) relay block 4 Wiring diagrams

relay block 4 wiring diagram (1 of 5)

List of components:

relay block 4 wiring diagram (2 of 5)

List of components:

relay block 4 wiring diagram (3 of 5)

List of components:

relay block 4 wiring diagram (4 of 5)

List of components:

relay block 4 wiring diagram (5 of 5)

List of components:
