Toyota Avalon XX50 (2018-2024) refreshing seat switch Wiring diagram
This page shows the only wiring diagram for the component.refreshing seat switch, which is found in the car Toyota Avalon XX50 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram refreshing seat switch (1 of 1)
BLK WIRE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LEFT FRONT SEAT CUSHION HEATER ASSEMBLY
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK SWL WIRE
PNK WIRE
PPL/BLK WIRE
PPL/RED WIRE
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
REFRESHING SEAT SWITCH
RELAY BLOCK 3
RELAY BLOCK 4
RELAY ENERGIZED
S/HTR F/L FUSE
S/HTR F/R FUSE
S/HTR F/R RELAY
S/HTR- MAIN FUSE
SEAT BACK HEATER
SEAT CUSHION HEATER
THL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Front heated seats circuit, w/ climate control seat (1 of 2) -> REFRESHING SEAT SWITCH
