Toyota Avalon XX50 (2018-2024) normal switch Wiring diagram
This page shows the only wiring diagram for the component.normal switch, which is found in the car Toyota Avalon XX50 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram normal switch (1 of 1)
ABSORBER CONTROL ECU
AVS FUSE
BLK WIRE
BLU WIRE
CAN STANDARD I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
EXCEPT HYBRID
FAL+
FAR-
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
HYBRID VEHICLE CONTROL ECU
IGB
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LEFT ACCELERATION SENSOR ASSEMBLY
LEFT FRONT SHOCK ABSORBER ASSEMBLY
LEFT FRONT SKID CONTROL SENSOR WIRE
LEFT REAR SHOCK ABSORBER ASSEMBLY
LT BLU WIRE
LT GRN WIRE
NORM
NORMAL SWITCH
NORMAL/ CUSTOM SWITCH
PNK WIRE
PWMS
RAL+
RAR+
RED WIRE
RIGHT ACCELERATION SENSOR ASSEMBLY
RIGHT FRONT SHOCK ABSORBER ASSEMBLY
RIGHT FRONT SKID CONTROL SENSOR WIRE
RIGHT REAR SHOCK ABSORBER ASSEMBLY
SGB
SGFL
SGFR
SGG
SPCN
SPORT S/S+ SWITCH
SPORT SWITCH
SPRT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic suspension circuit -> NORMAL SWITCH
