Toyota Avalon XX50 (2018-2024) hold switch Wiring diagrams
This page contains all the electrical diagrams for the component. hold switch, in which he is found in the car Toyota Avalon XX50 (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hold switch (1 of 3)
1 RELAY ENERGIZED
2 RELAY ENERGIZED
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
CAN STANDARD I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU- DCC 1 FUSE
ECU-B 2 FUSE
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
GRN WIRE
GRY WIRE
HOLD SWITCH
HOT AT ALL TIMES
IG+ IG+
IND
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
OUT
PNK WIRE
PPL/GRN WIRE
RED WIRE
RELEASE SWITCH
RIGHT END OF DASH)
RIGHT FRONT SKID CONTROL SENSOR WIRE
RIGHT FRONT SPEED SENSOR
STEERING SENSOR (ON STEERING COLUMN)
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
VACUUM WARNING SWITCH ASSEMBLY
VCM
VIO WIRE
W/O ADAPTIVE VARIABLE SUSPENSION
WHT WIRE
WHT/BLK WIRE
Go to component -> Anti-lock brakes circuit, except hybrid (2 of 2) -> HOLD SWITCH
Wiring diagram hold switch (2 of 3)
ABS 2 FUSE
ABS 3 FUSE
ABS MTR 1 FUSE
ABS MTR 2 FUSE
ABS MTR 3 FUSE
ABS- MAIN 1 FUSE
BLK WIRE
BLU WIRE
CAN STANDARD I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
EPB 1 FUSE
GRN WIRE
GRY WIRE
HOLD SWITCH
HOT AT ALL TIMES
IND
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/YEL WIRE
RE-
RED WIRE
RELEASE SWITCH
RIGHT PARKING BRAKE ACTUATOR ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Anti-lock brakes circuit, hybrid (2 of 3) -> HOLD SWITCH
Wiring diagram hold switch (3 of 3)
+BM
2.5L HYBRID
2.5L HYBRID 3.5L, 2.5L
3.5L, 2.5L
ABS 1 FUSE
BEPB
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY
CANH 11 4 19 2 CANL
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-B 2 FUSE
EGND
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
EPB 1 FUSE
GRN WIRE
GRY WIRE
HOLD SWITCH
HOT AT ALL TIMES
HZRI PNK WIRE
IND
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LE-
LEFT PARKING BRAKE ACTUATOR ASSEMBLY
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
MRL+
MRR
ORG/ WIRE
PNK WIRE
POL
PPL/BLU WIRE
PPL/GRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
RE-
RED WIRE
RELAY ENERGIZED
RELEASE SWITCH
RIGHT PARKING BRAKE ACTUATOR ASSEMBLY
STANDARD
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electric parking brake circuit -> HOLD SWITCH
