3.5l, transmission circuit for Toyota Avalon XX40 facelift (2015-2018)

3.5l, transmission circuit (1 of 3)

Avalon Toyota XX40 facelift (2015-2018): 3.5l, transmission circuit (1 of 3)

Get access

+BM BLK WIRE BLU WIRE BRN WIRE CAN (+) COMPUTER DATA LINES SYSTEM EFI 1 MAIN FUSE EFI MAIN RELAY ENGINE ROOM J/B ASSEMBLY ENGINE ROOM R/B ASSEMBLY ETCS FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES LT GRN WIRE ORG/ WIRE PADDLE SHIFT SWITCH STEERING PAD SWITCH ASSEMBLY PNK WIRE RED WIRE RELAY ENERGIZED SFTD SFTU SHIFT DOWN SHIFT UP SPIRAL CABLE SUB-ASSEMBLY STEERING COLUMN) THROTTLE BODY W/ MOTOR ASSEMBLY (RIGHT REAR OF ENGINE) TRANSMISSION CONTROL SWITCH (LOWER SHIFT LEVER ASSEMBLY) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

3.5l, transmission circuit (2 of 3)

Avalon Toyota XX40 facelift (2015-2018): 3.5l, transmission circuit (2 of 3)

Get access

1 RELAY ENERGIZED 2 RELAY ENERGIZED ANTI-LOCK BRAKES SYSTEM BKUP LP FUSE BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY BRN WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM ECU-B 1 FUSE ENGINE ROOM R/B ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B ASSEMBLY LED DRIVER LT GRN WIRE ORG/ WIRE OUT PARK/NEUTRAL POSITION SWITCH ASSEMBLY PNK WIRE RED WIRE SPEAKER STARTING/ CHARGING SYSTEM STOP FUSE STOP LIGHT SWITCH ASSEMBLY TELLTALE TFT DISPLAY DRIVER VIO WIRE W/ DYNAMIC RADAR CRUISE CONTROL W/O DYNAMIC RADAR CRUISE CONTROL WHT WIRE WHT/BLK WIRE YEL WIRE

3.5l, transmission circuit (3 of 3)

Avalon Toyota XX40 facelift (2015-2018): 3.5l, transmission circuit (3 of 3)

Get access

ACCELERATOR POSITION SENSOR ASSEMBLY BLK WIRE BLU WIRE BRN WIRE CAN (+) COMPUTER DATA LINES SYSTEM EFI 1 FUSE ENGINE ROOM R/B ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES OIL PRESSURE SWITCH TEMPERATURE SENSOR ORG/ WIRE PNK WIRE RED WIRE STARTING/ CHARGING SYSTEM TRANSMISSION CONTROL ECU ASSEMBLY WHT WIRE WHT/BLK WIRE YEL WIRE
