Rear window sun shade circuit for Toyota Avalon XX40 facelift (2015-2018)
Rear window sun shade circuit
BKUP LP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CURTAIN SWITCH ASSEMBLY
ECU-ACC FUSE
ECU-B 1 FUSE
ENGINE ROOM R/B 2 ASSEMBLY
ENGINE ROOM R/B ASSEMBLY
EXCEPT HYBRID
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC 1 RELAY ENERGIZED
HOT W/ IGCT RELAY ENERGIZED
HYBRID VEHICLE CONTROL ECU
INSTRUMENT PANEL J/B ASSEMBLY
LT BLU WIRE
MAIN BODY ECU
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PM IGCT FUSE
PNK WIRE
REAR SUNSHADE RELAY
REAR SUNSHADE SWITCH
RED WIRE
RELAY ENERGIZED
REV
SHIFT LEVER POSITION SENSOR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
