Power windows circuit for Toyota Avalon XX40 facelift (2015-2018)
Power windows circuit (1 of 2)
AUTO
DOOR LOCK, UNLOCK CONTROL SWITCH
DOWN
DRIVER SIDE AUTO SWITCH
DRIVER SIDE DOWN SWITCH
DRIVER SIDE POWER WINDOW SWITCH
DRIVER SIDE UP SWITCH
ECU-B 1 FUSE
ECU-B 2 FUSE
ENGINE ROOM R/B ASSEMBLY
F/L DOOR FUSE
F/R DOOR FUSE
FRONT PASSENGER SIDE POWER WINDOW SWITCH
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B ASSEMBLY
LED
LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR SIDE POWER WINDOW SWITCH
LIN
LT BLU WIRE
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR SIDE POWER WINDOW SWITCH
VIO WIRE
W/ MEMORY W/O MEMORY
WHT WIRE
WHT/BLK WIRE
WINDOW LOCK SWITCH
YEL WIRE
Power windows circuit (2 of 2)
AUTO
BLU WIRE
BRN WIRE
DOWN
ECU-ACC FUSE
GRN WIRE
HOT AT ALL TIMES
HOT W/ ACC 1 RELAY ENERGIZED
INSTRUMENT PANEL J/B ASSEMBLY
LED
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LIN
LT GRN WIRE
MAIN BODY ECU
ORG/ WIRE
PNK LIN WIRE
PNK WIRE
R/L DOOR FUSE
R/R DOOR FUSE
RED WIRE
RELAY ENERGIZED
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
VIO WIRE
WHT/BLK WIRE
YEL WIRE
