Power top/sunroof circuit for Toyota Avalon XX40 facelift (2015-2018)
Power top/sunroof circuit
BLU WIRE
CLS
COMPUTER DATA LINES SYSTEM
DOWN
ECU-ACC FUSE
ECU-B 1 FUSE
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
HOT AT ALL TIMES
HOT W/ ACC 1 RELAY ENERGIZED
INSTRUMENT PANEL J/B ASSEMBLY
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LIN
LT BLU WIRE
MAIN BODY ECU
OPN
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
ROOF CONSOLE BOX ASSEMBLY
S/ROOF FUSE
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY)
SLIDING ROOF CONTROL SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
