Cruise control circuit, hybrid for Toyota Avalon XX40 facelift (2015-2018)
Cruise control circuit, hybrid (1 of 2)
ACCELERATOR PEDAL SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
EFI 2 FUSE
EFI 3 FUSE
EFI MAIN 2 RELAY
EFI MAIN RELAY
EFI- MAIN 1 FUSE
EFI- MAIN 2 FUSE
ENGINE CONTROLS SYSTEM
ENGINE ROOM J/B ASSEMBLY
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
HYBRID VEHICLE CONTROL ECU
INSTRUMENT PANEL J/B ASSEMBLY
LT GRN WIRE
ORG/ WIRE
OUT
PNK WIRE
RED WIRE
SHIFT LEVER POSITION SENSOR
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
THROTTLE BODY W/ MOTOR ASSEMBLY (RIGHT REAR OF ENGINE)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Cruise control circuit, hybrid (2 of 2)
BLK WIRE
BRN WIRE
CAN I/F
CERTIFICATION ECU
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL SWITCH
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
GRY WIRE
HOT W/
LED DRIVER
LEFT FRONT SPEED SENSOR
LEFT REAR SPEED SENSOR
ON OFF
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT SPEED SENSOR
RIGHT REAR SPEED SENSOR
SHIELD
SKID CONTROL ECU W/ ACTUATOR (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY)
SPEAKER
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
WHT WIRE
WHT/BLK WIRE
