Toyota Avalon XX40 facelift (2015-2018) a/c amplifier assembly Wiring diagrams
This page contains all the electrical diagrams for the component. a/c amplifier assembly, in which he is found in the car Toyota Avalon XX40 facelift (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/c amplifier assembly (1 of 8)
A/C AMPLIFIER ASSEMBLY
A/C EVAPORATOR TEMPERATURE SENSOR
A/C PRESSURE SENSOR (A/C TUBE ASSEMBLY)
A/C UNIT (A/C HARNESS ASSEMBLY)
A/C-B FUSE
AMBIENT TEMPERATURE SENSOR (THERMISTOR ASSEMBLY)
B+ BUS
BLK WIRE
BLU WIRE
BLW
BRN WIRE
BUS -
BUS G
COLOR (RED) WIRE
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
CONNECTOR HOUSING
CONNECTOR HOUSING COLOR (BLACK)
CONNECTOR HOUSING COLOR (BLUE)
CONNECTOR HOUSING COLOR (GREEN)
CONNECTOR HOUSING COLOR (NATURAL)
DAMPER SERVO MOTOR (AIR INLET)
DAMPER SERVO MOTOR (AIR VENT MODE)
DAMPER SERVO MOTOR (LEFT FRONT SIDE AIR MIX)
DAMPER SERVO MOTOR (REAR SIDE AIR MIX)
DAMPER SERVO MOTOR (RIGHT FRONT SIDE AIR MIX)
DEFOGGER SYSTEM
ECO SWITCH
ECOS PNK TAM WIRE
FLOQ
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IND
INSTRUMENT PANEL J/B ASSEMBLY
LOCK
LT BLU WIRE
LT GRN WIRE
MGC
ORG/ WIRE
PNK TR WIRE
PNK WIRE
PRE
RDFG
RED WIRE
SEATS SYSTEM
SG-1
SG-2
SGA
SHD
SHP+
SOL +
SW 1
TEA
TSD
TSP
VIO WIRE
W/ PADDLE SHIFT SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, except hybrid (1 of 4) -> A/C AMPLIFIER ASSEMBLY
Wiring diagram a/c amplifier assembly (2 of 8)
A/C AMPLIFIER ASSEMBLY
A/C CONTROL ASSEMBLY
A/C CONTROL ASSEMBLY 2
ATIN
BLK WIRE
BLU WIRE
BRN WIRE
CLTB
CLTE
COMPUTER DATA LINES SYSTEM
ECU-ACC FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT PANEL J/B ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MIRROR HEATER SWITCH
ORG/ WIRE
PNK WIRE
REAR SEAT HEATER SWITCH
REAR WINDOW DEFOGGER SWITCH
RED WIRE
SEATS SYSTEM
SG-5
SG-6
SGND
SVDB
SVDI
SVDS
SVPB
SVPI
SVPS
SWD
TSET
TSL
TSR
VIO WIRE
W/ CLIMATE CONTROL SEAT
W/O CLIMATE CONTROL SEAT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, except hybrid (4 of 4) -> A/C AMPLIFIER ASSEMBLY
Wiring diagram a/c amplifier assembly (3 of 8)
A/C AMPLIFIER ASSEMBLY
A/C EVAPORATOR TEMPERATURE SENSOR
A/C PRESSURE SENSOR (A/C TUBE ASSEMBLY)
A/C UNIT (A/C HARNESS ASSEMBLY)
A/C-B FUSE
AMBIENT TEMPERATURE SENSOR (THERMISTOR ASSEMBLY)
B+ BUS
BLK WIRE
BLU WIRE
BLW
BRN WIRE
BUS -
BUS G
COLOR (RED) WIRE
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
CONNECTOR HOUSING
CONNECTOR HOUSING COLOR (BLACK)
CONNECTOR HOUSING COLOR (BLUE)
CONNECTOR HOUSING COLOR (GREEN)
CONNECTOR HOUSING COLOR (NATURAL)
DAMPER SERVO MOTOR (AIR INLET)
DAMPER SERVO MOTOR (AIR VENT MODE)
DAMPER SERVO MOTOR (LEFT FRONT SIDE AIR MIX)
DAMPER SERVO MOTOR (REAR SIDE AIR MIX)
DAMPER SERVO MOTOR (RIGHT FRONT SIDE AIR MIX)
DEFOGGER SYSTEM
ECO SWITCH
ECOS PNK TAM WIRE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IDH
IND
INSTRUMENT PANEL J/B ASSEMBLY
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PRE
RDFG
RED WIRE
RH PNK TR WIRE
SEATS SYSTEM
SG-1
SG-2
SG-4
SGA
SHD
SHP+
SW 1
TEA
TFG
TNG
TSD
TSP
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, hybrid (1 of 4) -> A/C AMPLIFIER ASSEMBLY
Wiring diagram a/c amplifier assembly (4 of 8)
A/C AMPLIFIER ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRN WIRE
CANN
CANP
CAYH
CAYL
CERTIFICATION ECU (RIGHT END OF DASH)
COMBINATION METER ASSEMBLY
CSPT
DOOR LOCKS, ANTI-THEFT SYSTEMS
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
ILSW
IND
INSTRUMENT PANEL J/B ASSEMBLY
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY (LEFT FRONT POWER SEAT SWITCH)
LLEW
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MEMORY SYSTEMS
MIRB
MIRE
MIRS
NAVIGATION RECEIVER ASSEMBLY
NETWORK GATEWAY ECU (IF EQUIPPED) (RIGHT END OF DASH)
ORG/ WIRE
OSPT
PNK WIRE
RED WIRE
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RLEW
STEERING SENSOR
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TSW
VIO WIRE
W/ NAVIGATION W/O NAVIGATION W/ NETWORK GATEWAY ECU W/O NETWORK GATEWAY ECU
WHT WIRE
WHT/BLK WIRE
Go to component -> Body ecu circuit, except hybrid (2 of 2) -> A/C AMPLIFIER ASSEMBLY
Wiring diagram a/c amplifier assembly (5 of 8)
A/C AMPLIFIER ASSEMBLY
AIR BAG SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY
BRN WIRE
CANN
CANP
CAYH
CAYL
CERTIFICATION ECU (RIGHT END OF DASH)
CSPT
DATA LINK CONNECTOR 3
DRIVER'S DOOR
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
ILSW
IND
INSTRUMENT PANEL J/B ASSEMBLY
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY (LEFT FRONT POWER SEAT SWITCH)
LLEW
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MEMORY SYSTEMS
MIRB
MIRE
MIRS
NAVIGATION RECEIVER ASSEMBLY
NETWORK GATEWAY ECU (W/ DYNAMIC RADAR CRUISE CONTROL)
ORG/ WIRE
OSPT
PNK WIRE
POWER STEERING ECU
RED WIRE
RIGHT END OF DASH)
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RLEW
SKID CONTROL ECU W/ ACTUATOR
SOUND SYSTEMS
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TSW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Body ecu circuit, hybrid (2 of 2) -> A/C AMPLIFIER ASSEMBLY
Wiring diagram a/c amplifier assembly (6 of 8)
A/C AMPLIFIER ASSEMBLY
AIR BAG SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRN WIRE
CAN (+)
CANN
CANP
CERTIFICATION ECU (RIGHT END OF DASH)
COMBINATION METER ASSEMBLY
DATA LINK CONNECTOR 3
DCM (TELEMATICS TRANSCEIVER)
GRN WIRE
GRY WIRE
HEADLIGHT LEVELING ECU
HOT AT ALL TIMES
INIT
INSTRUMENT PANEL J/B ASSEMBLY
LEFT "C" PILLAR)
LIMIT SWITCH
LT BLU WIRE
LT GRN WIRE
LVL
MAIN BODY ECU
NAVIGATION RECEIVER ASSEMBLY
OBD FUSE
OCCUPANT DETECTION ECU
ORG/ WIRE
PNK WIRE
POWER STEERING ECU ASSEMBLY
PRST
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
RIGHT FRONT SEAT INNER BELT ASSEMBLY
SIL
STEERING SENSOR
TAC
TACH
TRANSMISSION CONTROL ECU ASSEMBLY
VIO WIRE
W/ CLIMATE CONTROL SEAT
W/ MEMORY
W/ NAVIGATION
W/ NETWORK GATEWAY ECU W/O NETWORK GATEWAY ECU
W/ SAFETY CONNECT
W/O CLIMATE CONTROL SEAT
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Computer data lines circuit, except hybrid (1 of 2) -> A/C AMPLIFIER ASSEMBLY
Wiring diagram a/c amplifier assembly (7 of 8)
11 SPEAKER
A/C AMPLIFIER ASSEMBLY
A/C CONTROL ASSEMBLY
A/C CONTROL ASSEMBLY 2
BLK WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BRN WIRE
CAN 1 JUNCTION TERMINAL
CHECK CONNECTOR
COMBINATION METER ASSEMBLY
DATA LINK CONNECTOR 3
DCM
DOOR CONTROL SWITCH ASSEMBLY
FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 2 OF 4)
FUEL PUMP CONTROL ECU ASSEMBLY
GLASS BREAKAGE SENSOR ECU ASSEMBLY
GLOVE BOX LIGHT
HAZARD WARNING SIGNAL SWITCH ASSEMBLY
HEADLIGHT DIMMER SWITCH ASSEMBLY
LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY
NAVIGATION RECEIVER ASSEMBLY
NETWORK GATEWAY ECU
POWER OUTLET SOCKET ASSEMBLY 2
POWER STEERING ECU ASSEMBLY
RADIO, DISPLAY RECEIVER ASSEMBLY
REFRESHING SEAT SWITCH
REMOTE ENGINE STARTER ECU
RIGHT FRONT DOOR AMBIENT LIGHT
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT FRONT ELECTRICAL KEY ANTENNA
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RIGHT POWER OUTLET SOCKET ASSEMBLY 1
SHIFT LOCK CONTROL ECU
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING LOCK ACTUATOR ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
STEERING SENSOR
STEREO COMPONENT AMPLIFIER ASSEMBLY
TIRE PRESSURE WARNING RESET SWITCH
W/ ENTRY FUNCTION
W/ FRONT FOG LIGHT
W/ GLASS BREAKAGE SENSOR
W/ MEMORY
W/ SAFETY CONNECT
W/ SEAT HEATER W/O SEAT HEATER
W/O MEMORY
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Ground distribution circuit, except hybrid (3 of 4) -> A/C AMPLIFIER ASSEMBLY
Wiring diagram a/c amplifier assembly (8 of 8)
11 SPEAKER
A/C AMPLIFIER ASSEMBLY
A/C CONTROL ASSEMBLY
A/C CONTROL ASSEMBLY 2
BLK WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BRN WIRE
CAN 1 JUNCTION TERMINAL
CERTIFICATION ECU
CHECK CONNECTOR
COMBINATION METER ASSEMBLY
DATA LINK CONNECTOR 3
DCM
DOOR CONTROL SWITCH ASSEMBLY
FROM INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 2 OF 4)
GLASS BREAKAGE SENSOR ECU ASSEMBLY
GLOVE BOX LIGHT
HAZARD WARNING SIGNAL SWITCH ASSEMBLY
HEADLIGHT DIMMER SWITCH ASSEMBLY
LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY
NAVIGATION RECEIVER ASSEMBLY
NETWORK GATEWAY ECU
POWER OUTLET SOCKET ASSEMBLY 2
POWER STEERING ECU ASSEMBLY
RADIO, DISPLAY RECEIVER ASSEMBLY
REFRESHING SEAT SWITCH
REMOTE ENGINE STARTER ECU
RIGHT FRONT DOOR AMBIENT LIGHT
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT FRONT ELECTRICAL KEY ANTENNA
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RIGHT POWER OUTLET SOCKET ASSEMBLY 1
SHIFT LOCK CONTROL ECU
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING LOCK ACTUATOR ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
STEERING SENSOR
STEREO COMPONENT AMPLIFIER ASSEMBLY
TIRE PRESSURE WARNING RESET SWITCH
VEHICLE APPROACHING SPEAKER CONTROLLER
W/ MEMORY
W/ POWER OUTLET W/O POWER OUTLET
W/ SAFETY CONNECT
W/O MEMORY
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Ground distribution circuit, hybrid (3 of 4) -> A/C AMPLIFIER ASSEMBLY
